8 port 1000M Fiber switch WEB or SNMP optional

8 port 1000M Fiber switch WEB or SNMP optional 1

8 port 1000M Fiber switch WEB or SNMP optional 2

8 port 1000M Fiber switch WEB or SNMP optional 3

Model:	FOWAY1509FCM
Brand:	HIOSO
Origin:	Made In China
Category:	Electronics & Electricity / Telecommunication & Broadcasting / Network Communications Equipment
Label:	switch , fiber switch , managed fiber switch
Price:	US $100 / pc
Min. Order:	1 pc

Inquire Now Add to Basket

Member Information

Haishuo Trading Company Limited

Free MemberGuang Dong - China

Live Chat:

Last Online:20 Feb, 2018

Product Description

Overview

HiOSO FOWAY1509FC is a nine ports Gigabit fiber switch, with 8 1000M SFP fiber ports and 1 1000M Combo port (100M / 1000M SFP port or 10/100/1000M RJ45 port optional) uplink.

FOWAY1509FC supports SFP modules hot plug, and supports to work with other fiber switches, fiber converters and other devices with fiber ports. It supports WEB management; applies to security system, electric system, traffic system requirements.

Character

Support 8 Gigabit SFP access and 1 Gigabit Combo port (100M or 1000M SFP optional, or 10/100/1000M RJ45 port)
Support SFP hot plug
Support full rate, full-duplex non-blocking forwarding at each port
Support 8K MAC learning, 1Mbit storage and forward cache space, 18G back plane bandwidth
Supports to substitute central fiber converter, simplify network structure, lower network establishing cost, reduce device fault
All optic ports, strengthen the an-interference ability
Metal casing design, better for heat dissipation

Technical Specification

Parameter	Specification
Standard	IEEE802.3 10Base-T Ethernet,IEEE802.3u 100Base-TX/FX Fast Ethernet, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX Gigabit Ethernet, IEEE802.1d Spanning Tree
Wavelength	SFP:850nm/1310nm/1490nm/1550nm
Distance	100M SFP Multi-mode: 2km (fiber size 62.5/125μm or 50/125μm) Single-mode: 20/40/60/80/100/120Km Single-fiber single-mode: 25/40/60/80/100/120Km 1000M SFP Multi-mode: 220m (fiber size 62.5/125μm) / 550m(fiber size 50/125μm) Single-mode: 10/20/40/60/80/100/120Km Single-fiber single-mode:10/20/40/60/80/100/120Km CAT5: 100m
Port	8 Gigabit SFP fiber ports: 1000Mbps 1 Gigabit Combo port:: 1 Gbps, 100M/1000M SFP&10/100/1000M RJ45
MAC	8K
Buffer memory space	1Mbit
Bit error rate	<1/1000000000
MTBF	100000 hours
Power	DC12V/2A
Power consumption	10W
Working temperature	-10~60℃
Storage temperature	-40~80℃
Humidity	5%~90% non-condensing
Dimension	28mm (H)×193mm(W)×119mm (D)

Order information

No	Type	Managed	Ports
1	FOWAY1509FC	Not	8 1000Base-FX SFP ports + 1 Gigabit Combo uplink (SFP fiber port /RJ45 Ethernet port optional)
2	FOWAY1509FCM	Support	8 1000Base-FX SFP ports + 1Gigabit Combo uplink ((SFP fiber port /RJ45 Ethernet port optional)

Product Image

Img 1

Img 2

Img 3

Img 4

Img 5
