4+1 5 port ethernet switch 100M switch

Model:FOWAY2205TF
Brand:OEM
Origin:Made In China
Category:Electronics & Electricity / Telecommunication & Broadcasting / Network Communications Equipment
Label:ethernet switch , 5 port switch , switch
Price: US $45 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Haishuo Trading Company Limited

Free MemberGuang Dong - China
Live Chat:
点击这里给我发消息Last Online:20 Feb, 2018

Product Description

Overview



HiOSO Foway2205TF series 5 ports 100M Security Industrial Ethernet Switches, supply 4 10/100M RJ45 ports and 1 100M FX uplink port; support to choose web or SNMP management; support to transmit HD video flow; apply to Security system, electronic power system and traffic system requirements.





Character

  • Support 4 10/100M RJ45 ports and 1 100M FX uplink port
  • Support each port full rate, full-duplex non-blocking forwarding
  • Support WEB management and SNMP (optional)
  • Support 2K MAC learning, 1Mbit storage and forward cache space
  • Each RJ45 port adopts anti-high voltage circuit, strengthen the lightning protection and anti-interference ability
  • Supply redundant dual power input ports, enhance reliability
  • Metal casing with wall mounting design, external power , better for heat dissipating and installation



Technical Specification

Parameter

Specification

Standard

IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX/FX Fast Ethernet,IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS, IEEE802.1d Spanning Tree

Wavelength

850nm/1310nm/1490nm/1550nm

Transmission distance

100M fiber:

multi-mode: 2km

Single-mode:25/40/60/80/100/120Km;

Single-fiber single-mode:25/40/60/80/100/120Km;

CAT5: 100M

Ports

4 10/100M RJ45 ports: 10/100Mbs

1 100M FX uplink port: 100Mbps SC/FC/ST fiber port

MAC

2K

Buffer memory space

1Mbit

Bit error rate

<1/1000000000

MTBF

100000 hours

Power

DC12V/1A dual input redundant backup

Power consumption

3.5W

Working temperature

Common:-10~60℃; -T (wide temperature range):-40~75℃

Storage temperature

-40~80℃

Humidity

5%~90% non-condensing

Installation

Wall mounting type

Dimension

26mm (H)×140mm(W)×106mm (D)

Order information

No

Type

NMS

Ports

1

Foway2205TF

   NO

4 10/100M RJ45 ports + 1 100M FX uplink

2

Foway2205TFM

YES

4 10/100M RJ45 ports + 1 100M FX uplink



No

Type

NMS

Ports

1

Foway2205T

   NO

4 10/100M RJ45 ports + 1 10/100M RJ45 uplink

2

Foway2205TM

YES

4 10/100M RJ45 ports + 1 10/100M RJ45 uplink


Product Image

4+1 5 port ethernet switch 100M switch 1
Img 1
4+1 5 port ethernet switch 100M switch 2
Img 2
4+1 5 port ethernet switch 100M switch 3
Img 3
4+1 5 port ethernet switch 100M switch 4
Img 4
4+1 5 port ethernet switch 100M switch 5
Img 5
