| Model: | RS650QUB-GD30 |
|---|---|
| Brand: | RisingStar |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | display , lcd display |
| Price: |
US $599
/ pc
|
| Min. Order: | 1 pc |
| Last Online:13 Jun, 2025 |
RS650QUB-GD30 Specification
| Panel Brand | RisingStar | Panel Model | RS650QUB-GD30 |
| Panel Size | 65″ | Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 3840(RGB)×2160 | Pixel Format | RGB Vertical Stripe |
| Display Area | 1428.48(H)×803.52(V) mm (A.A) | LCD screen | S-IPS |
| Outline Size | 1461(H) × 843.1(V) × 60.3(D) mm | Surface | Hard coating(3H), Anti-glare low reflection treatment of the front polarizer (Haze 2%(Typ.)) |
| Brightness | 3000 cd/m²or customized | Contrast Ratio | 1200:1 (Typ.) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | Display Mode | Normally Black, Transmissive |
| Display Colors | 1.07B 99% sRGB | Response Time | 6 (Typ.)(Tr/Td) ms |
| Frequency | 60Hz | Supply voltage | 12.0V (Typ.) |
| Weight | TBD (Typ./Max.) | Signal Interface | LVDS 51 pins |
| Environment | Operating Temp.:-20℃~70℃; Storage Temp.:-20℃~70℃ | ||
。
。
