| Model: | GT-C26B |
|---|---|
| Brand: | GESTER |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Analysis Instrument |
| Label: | Hydrostatic Head Tes , Waterproof Tester , Textile Test Machine |
| Price: |
US $7560
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:04 Aug, 2023 |
Application
Hydrostatic Tester is used to test the waterproof
properties of fabric through waterproofing work such
as canvas, coated fabrics, hood fabric, tarpaulin,
rain-proof fabrics and geotextile.
Feature
The pressure using dynamic feedback regulation effectively prevent pressure overshoot.
Japan Panasonic servo motor and drive system, 16-bit A / D conversion.
Whole machine with aluminum alloy structure.
Sensor protection : automatic overload protection ( automatic switching of multi-sensor range).
Standards
AATCC 127, ISO 811, ISO 1420, GB/T4744, FZT01004, DIN53886, JIS L1092, EN20811
Specification
| Model | GT-C26B-1 | GT-C26B-2 | GT-C26B-3 |
| Testing range | 200kpa | 500kpa | 1000kpa |
| Pressure resolution | 1 /10000 ; | ||
| Accuracy | ≤1% | ||
| Control mode | Touch screen control or tablet PC control (optional) | ||
| Testing modes | 5 Test modes：
P. Rise Const P & Timing |
||
| Specimen area | 100cm², or 7.8cm2 (Option) | ||
| Testing unit | pa, Kpa, mmHg, cmH2O | ||
| Pneumatic clamping load | 0-30000N (stepless adjustable) | ||
| Pressurized speed | 0.01Pa to 100KPa/min (stepless adjustable) | ||
| Power supply | AC 220V 50/60HZ | ||
| Dimensions | 420x580x700mm (L x W x H) | ||
| Weight | 60 kg | ||
| Payment Terms: | TT / LC |
|---|---|
