Apllication

This machine is designed for tearing resistance of textile, non-woven fabrics, paper, paper board, thin film, ventilation tape, metal sheet materials and etc.

Feature

• Advanced calculation methods make sure precision test & good repetition.
• Microcomputer system, can do auto test, calculate, analysis result, print test report.
• Upload the test data.
• Humanity operation system, Chinese and English operation interface with easy & convenience methods.
• Can look up all the datum & statistical result in mainframe freely.
• Test unit can convention between N, gf, cN and ibs, suitable for differents standards requirements automatically.
• Pneumatic sample grips and pendulum bob released to make sure equal clamping force.
• Cut sample automatically, making sure same shape of notch, reducing operation strength.

Standards

Textile: GB/T3917.1, ASTM D1424, DIN 53862, ISO13937-1, ISO4674-2, ISO9290, M&S P29, NF G07-149

Paper: GB/T455, APPITA P400, ASTM D689, BS 4468, CSA D9,DIN 53128, EN 21974,ISO 1974, JIS P8116, PAPTAC D9, SCAN P11,SNV 198482, TAPPI T414, UNI 6444

Plastic: GB/T11999, ASTM D1922, ISO6383-2, JIS K7128-2

Non-woven: ASTMD5734
