| Model: | ES |
|---|---|
| Brand: | NOELIFT |
| Origin: | Made In China |
| Category: | Transportation / Logistics / Forklifts, Pallet Trucks |
| Label: | pallet truck , froklift , pallet stacker |
| Price: |
US $1111
/ pc
|
| Min. Order: | 1 pc |
| Last Online:17 Oct, 2016 |
Features
1: Smart body, with attractive appearance. High-strength frame designed for tough pallet handling tasks.
2: Lower consumption, Lower service cost, while higher performance.
3: 24V/65AH(80AH optional) maintenance free battery contributes to strong power and easier operation.
4: Compact structure and reasonable layouts provides steadiness and durability during operation.
Performance
1: Ergonomically designed and built Handle is increasing your comfort during operation. Dustproof and sealing structure prevent it from dust pollution damages and improve service life.
2: Intelligent and modular controlling system ensures the steadiness and safety for walking, lifting, lowering and braking.
3: Handle is utilized for easier operation and less turing radius, suitable for confined space and narrow aisle.
Safety
1: The Anti-Reverse safety button mounted at the top of the handle reverses the truck direction to prevent the operator from being caught between the truck and the obstacle on unexpected occasions.
2: Intelligent controller takes protection measures in case of over voltage, low voltage, over current, over temperature and short circuit occasions.
3: Especially innovated speed deceleration system automatically reduces the travel speed when turning and greatlyimproved the loading stability, avoiding possibility of load tipping over and making operate safer.(Optional)
Serviceability
1: Self-Diagnostics provided direct fault code readout during operation and start up, which is ease of service andmaintenance.
2: 24V/65AH(80AH optional) maintenance free battery contributes to strong power and easier operation, meeting most requirements for light and medium duty applications
3: Built-in charger practically eliminates contamination entry, which can result in failure.
Specifiction
| Condition | new |
| Place of Origin | Zhejiang, China (Mainland) |
| Brand Name | NOELIFT |
| Model Number | ES10M, ES15M |
| Type | Powered Pallet Truck |
| Power Source | DC Motor |
| Rated Loading Capacity | 1000-1500kg |
| Max. Lifting Height | 3000mm |
| Min. Lifting Height | 1600mm |
| Fork Size | 1150x160x50mm |
| Overall Dimensions | 1716x800x2150mm |
| electric stacker drive speed | 5.5km/h |
| electric stacker lifting motor | 2.20kw DC |
| electric stacker drive motor | 0.75kw DC |
| electric stacker battery | 24/80V/Ah |
| electric stacker lifting speed | 0.22m/s |
| electric stacker controller | PG/CURTIS |
| tire type | PU |
| parking brake | electrimagnetic |
| electric stacker color | red/green |
product details
Packaging & Shipping
International packing way, packed with thick plastic film.
