Model

ETVC4102-0436-S

DTVC4104-0436-S

Detection

Vehicle:1700m

Human:720m

Vehicle:3400m

Human: 1400m

Identification

Vehicle:420m

Human: 180m

Vehicle: 840m

Human: 360m

Thermal sensor

336*256, 5th generation UFPA, 50mk NETD, 7.5-14um spectral response

Thermal lens

20mmF1.0

40mmF1.0

FOV

15.5°X 11.6°

8°X 6°

Visible

440,000 pixels, 1/4''CCD, auto color to B/W at 0.01lux

Lens

3.4mm-122.4mm, 36X, auto focus

PT

Pan: 360° continuous; tilt: -60°～+90°

Rotation speed

Pan: 0.01°～100°/s; Tilt: 0.01°～90°/s

Preset

255, breakpoint memory

Auto mode

6 patrols/4 scanning/ 1self-learning

Path

1 self-learning path, 160 seconds

Auto watch

Available homing time, preset, patrol and scanning

Menu

English/Chinese OSD

Compass

Automatic calculation of orientation

Wiper

One-time and continuous

Protocol

Pelco-P/D and other mainstream protocols

Baud rate

2400/4800/9600/19200bps

Ingress protection

IP66，TVS1500V  anti-lighting and surging

Working temp.

-30~60℃, ＜90%RH  non-condensing

Power supply

DC10V-18V

Dimension and weight

Φ230(mm)×348(mm), 5kg
