Model

TVC4307-1930-IP

TVC4510-2030-IP

TVC4515-2050-IP

Detection

Vehicle: 6500m

Human: 2500m

Vehicle: 8600m

Human: 3400m

Vehicle: 13000m

Human: 4800m

Identification

Vehicle:1800m

Human: 700m

Vehicle: 2400m

Human: 900m

Vehicle: 3400m

Human: 1300m

Thermal

sensor

VOx uncooled detector, 324*256(640*512 optional); 7.5um-14um spectral response, 50mk NETD, 2X digital zoom; Image processing; AGC; 10 pseudo color; SDE image enhancement;

Thermal

lens

25mm～75mm

21mm～105mm

31mm～155mm

3CAM precision mechanizing(auto focus optional)

FOV

13°～4.3°

18°～3.4°

11.2°～2.2°

Visible camera

1/2.8'' Sony CMOS, 2.1 mega pixels, 1920*1080, auto B/W to color at 0.001lux; ICR optical filter; H.264

Lens

4.3mm～129mm, mega pixels, auto focus

12～320mm, mega pixels, motorized zoom and focus, auto iris

15～528mm,mega pixels, motorized zoom and focus, auto iris(25～750mmoptional)

Housing

Aluminum alloy housing, double window, water-tight, IP66 rated

Load duty

30kg

50kg

PT

Pan: 360o continuous; tilt:+40°～-75°

Pan: 360o continuous; Tilt: +45°～-45°

Rotation speed

Pan:0.01～60°/S; tilt: 0.01～30°/S

Pan: 0.01～30°/S; tilt: 0.01～15°/S

Extended

function

Real time display of orientation and angle; zero correction; angle back sending; presets, patrol and scanning

Video

 H.264, 2 video output

Interface

IP box, 1*RJ45 for all video outputs and control

1*AC24V power

Protocol

Pelco-D/P; 2400/4800/9600/19200(selectable baud rates)

Anti-lighting

4000V(power supply); 2000V(communication)

Power supply

AC24V±10%，50Hz，5A

Ingress Protection

IP66

Working temp.

-25℃～+55℃(-40℃ optional)

Weight

≤50kg(PT included)

Dimension

570mm×340mm×580mm(L×W×H)
