Explosion-proof high-speed dome camera 1
  • Explosion-proof high-speed dome camera 1

Explosion-proof high-speed dome camera

Model:SWGQ-Ex
Brand:-
Origin:Made In China
Category:Security & Protection / Surveillance Equipment
Label:Ex high-speed dome , Ex PTZ camera , Ex proof camera
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Shenzhen Mlc Technology Co.,Ltd

Free MemberGuang Dong - China
Live Chat:Last Online:15 Jul, 2022

Product Description

 SWGQ-EX series of explosion-proof high-speed dome with superior performance, useHikvision DS2006 130W pixels HD original camera, clear image, stable performance, high integration, convenient installation and use, seamless docking with the Hikvision NVR, platform software, etc. Can be used for horizontal scanning (360 degree horizontal continuous rotation), pitching rotation,Applicable to the petroleum, chemical industry, mine, military, medicine, oil depot, ships, drilling platforms and other large industrial enterprises; the explosion-proof high-speed dome can rotate 360 degrees in a few tenths of a second by the preset point, cruise, fast sweep, slow sweep, maximum extent to avoid the blind spot of the monitoring, win the affection of majority of system integrators, contractors, customers

The product is inspected by the national explosion-proof electrical product quality inspection and testing center and made explosion-proof certification.

Product features

  • Built-in Hikvision DS2006 HD original cameraseamless docking with the Hikvisionproducts, clear image
  • With internal storage function, support the installation of micro SD
  • Up to 130W pixels, 720P real-time image output, support multi stream
  • ICR filters of switching function, low illumination automatic color to black
  • Leading the industry code algorithm, provides broadcast level image quality
  • Three streams to adapt more monitoring scene, high compression ratio, high video quality
  • High signal-to-noise ratio, the picture clear, clean and transparent
  • Using the advanced 3D dynamic intelligent noise reduction features
  • Embedded Web Server, video browsing, parameter configuration, upgrade, authority management
  • Intelligent variable speed function, PTZ speed automatic adjustment with the depth of field
  • The real integrative equipment, easy to install and cost savings
  • Continuously 360° horizontal rotation and vertical 180°auto-flip
  • Using high quality servo motor, the positioning is accurate
  • Black hood, the camera is more hidden
  • Built-in lightning-proof protection, lightning-proof, surge-proof
  • Support the preset point line cruise route(27 preset point/route)
  • 1 scan lines, 4 regional privacy protection
  • Run memory automatically, prevent loss after power down, recovery to run automatically after manual operation
  • Heating function optional, can be used in low temperature environment
  • Variety of power supply mode options: AC/DC12V-30V/AC220V
  • Bottom housing made of polycarbonate composite aviation material, hardened, anti-fog treatment, with sufficient strength and excellent corrosion resistance
  • The material of the housing is high hardness of 304 stainless steel, beautiful appearance, corrosion resistant, durable

 Technical parameters

Model

SWGQ-EX

Ex mark

ExdⅡCT6 Gb

IP

IP66

Image sensor

DS-2ZCN2006,1/3" Progressive Scan CMOS

Resolution

130W pixels (HD720P,Resolution 1280×960

Lens

20X optical zoom f=4.7 to 94mm(F1.6 to F3.5),12X digital zoom(240X zoom)

Angle of view

720 P mode 58.3°(wide angle) to 3.2°(tele-converter

Min illumination

Color:0.05Lux @ (F1.6,AGC ON)

Black & White:0.01Lux @(F1.6,AGC ON)

Day and night switching

Automatic(ICR automatic switching

Electronic shutter

1/1s to 1/10000s

White balance

Automatic、Indoor、Outdoor、Manual

AE controlling

Automatic、Manual、Priority mode

AGC

Automatic

Wide dynamic

Close/open,4 level is adjustable

Storage function

Support micro SD

Intelligent alarm

Motion detection, occlusion alarm, memory is full, the memory fault

Output format

130W pixels (Resolution 1280×960

Transmission mode

RJ45 interface,Wired network transmission

Network protocols

HTTP,TCP/IP,ICMP,RTSP,RTP,UDP,RTCP,

SMTP,FTP,DHCP,DNS,DDNS,PPPOE,UPnP

Speed

0.08°—300°/S

Panning range

Continuously 360° ​​rotation

Tilt range

0°—90°

Preset precision

±0.1°

Preset

220

Auto Cruise

1

Mode records

1,Recording time less than 180 seconds

Area set

4,support scanning in the area

Power supply

AC/DC12~30V(AC220V optional)

Working current

<2A

Consumed power

≤20W(without heating

Environment temperature

Operating temperature -10℃~+70℃,Operating humidity 10%~90%

Heater

0℃±5℃ open,8℃±3℃ disconnect

Outlet hole specifications

One of G-1/2″ interface

Weight

≤20kg


Payment Terms:TT/WESTERN UNION

Product Image

Explosion-proof high-speed dome camera 1
