| Model: | SWKB-Ex |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Security & Protection / Surveillance Equipment |
| Label: | ex proof camera , ex proof housing , ex proof cameras |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:15 Jul, 2022 |
The product is designed,produced and tested according to the GB3836.1-2010 and GB3836.2-2010 "Explosion proof electric equipment in Explosion gas envionment"
Grade of Explosion-proof：ExdⅡBT6
Material：Special Carbon Steel
Application environment:
It is suitable for dangerous explosion gas environment. The explosion gas is class IIA,IIB and IIC and the environment group is in the temperature from T1-T6 in Area No.1,No.2,No.20,No.21 and No.22.Such as oil field, chemical plant, steamship, gas station, curative, gas storeroom and so on.
The product is inspected by the national explosion-proof electrical product quality inspection and testing center and made explosion-proof certification.
Product features：
Technical parameters：
|
Model |
SWKB-EX06 |
|
Ex mark |
Exd IIBT6 Gb |
|
IP |
IP66 |
|
Image sensor |
Optional |
|
Power supply |
DC12V/1A or AC220V optional |
|
External dimension |
￠113mm ×350 mm(L) |
|
Inside dimension |
￠105mm ×265mm(L) |
|
Environment temperature |
Working temperature -10℃~+70℃，Working humidity 10%~90% |
|
Outlet hole specifications |
2 of G-1/2″ |
|
Weight |
≤8kg |
| Payment Terms: | T/T |
|---|---|
