Quick CNC Router CNC engraving machine K30MT/1212

Quick CNC Router CNC engraving machine K30MT/1212 1

Model:	K30MT/1212
Brand:	QUICK CNC
Origin:	Made In China
Category:	Industrial Supplies / Machinery / Engraving & Etching Machine
Label:	CNC router , engraving machine , woodworking machine
Price:	-
Min. Order:	1 pc

Inquire Now Add to Basket

Member Information

Jinan Quick-Fulltek CNC Machinery Co., Ltd.

Free MemberShan Dong - China

Live Chat:

Last Online:09 Jul, 2023

Product Description

Model	K30MT/1212
X-Y-Z axis working area	1,200 x 1,200 x 200mm
Machine size	1750 x 1750 x 1600mm
Repositioning resolution	0.02mm
System Resolution	0.0025mm
X-Y movement	rack and pinion, gear drive/Taiwan
Z movement	ball screw drive/Germany
Guide	Linear ￠20 square/Taiwan
Max. speed	35,000mm/min
Max. cutting speed	25,000mm/min
Spindle power	3kw(water cooling) /Japan NSK
Spindle speed	24,000rpm
Inverter power	3.7kw
Drive motors	stepper
Working voltage	AC380V/50-60Hz,3-phase (Opition:AC220V/50-60Hz, 1-phase)
Command code	G code
Computer interface	USB 2.2
Collet	ER20- 3.175mm, 6mm, 12.7mm
Software	Artcam & Alphacam Software/UK
Controls	DSP A11 (Digital Signal Processor)
Packing dimensions	1960 x 2000 x 1700mm, 900 Kgs
Standard equipment included	1. Auto tool surface sensor 2. Manual oil lubrication system 3. Dust hood 4. T-slot vacuum table 5. Regenerative blower 7.5Kw

Product Image

Img 1

Img 2

Img 3
