Portable ultrasonic flow transmitter with RS485 output
Portable ultrasonic flow meter takes a state-of-the-art transit time measurement principle in digital signal processing. It is designed to work with the clamp on transducer, to provide accurate measurement of liquid flow within a closed pipe line.There is not any mechanical parts to be inserted into the pipe wall Or to protrude into the flow system. It just takes a few minutes to install, and it is not necessary to shut down the flow or drain the system.
1.Accuracy:Better than ±1.0%
5.Measurement Principle:Transit-time measurement principle
6.Display:LCD with back light, 2x20 letters
7.Keypad:4x4+2 key membrane keypad with tactile feedback
8.Unit:English(US.) or metric
9.Output: 1 Channel isolated RS485 output
10.Pipe material:All metal, most of plastic, fiber glass, etc. Allow the pipe liner.
11.Pipe Size:1/2-240" (DN15mm-6000mm)
12.Liquid Types: Virtually all clean liquids
13.Liquid Temperature:-40~160 degree celsuis
14.Power: Ni-MH battery powered, can work continuously more than 24 hours.
15.Weight:Main unit: 2.5kg
16.Enclosure:Die-cast aluminum enclosure
17.Protective class: IP65
18.Enclosure Size: 210x200x100mm
19.Communication protocol: MODBUS, M-BUS,ect
20.Transducer: Clamp on type
21.Transducer cable: 5Mx2 standard.
