TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera

Model:TP210
Brand:TianYing or OEM
Origin:Made In China
Category:Security & Protection / Surveillance Equipment
Label:thermal camera , camera , thermal imaging
Price: -
Min. Order:10 pc
Inquire Now Add to Basket

Member Information

Detail

Yiwu Tianying Optical Instrument Co., Limited

Biz MemberZhe Jiang - China
Live Chat:
Last Online:27 May, 2020

Product Description

TP210 Dual Sensor Infrared Body Temperature Screening Thermal Imaging Camera Features:
1, 70mk uncooled sensor with 210x160;

2, Non-contact temperature measurement, temperature error ≤ ±0.5ºC in room ambient temperature;

3, Effective range: 1.5m;

4, Measuring speed: 21ms;

5, Support abnormal temperature alarm function;

6, Accurately locate temperature measurement sites and reduce false reporting rate;

7, 3.5" inches color 640x480 TFT display;

8, Visual camera: 300000 pixel, auto focus;

9, Temperature range: +20ºC~+45ºC and -20 ºC~+330 ºC (manual switching);

10, Non-contact temperature monitoring and monitoring for 24 hours, and visualize the information;

Applications :  Airport,  Station, Hospital, School, Enterprises and institutions.

Question:
1, Why many dual sensor measurement body temperature thermal device price is very cheap?

Because the quality of their products is not guaranteed, also their factory is only assembly device and cut corners.

2, Why measurement accuracy must note ambient temperature?

Because ambient temperature will affect measuring accuracy, also ambient temperature of each model product is different for accurate measurement.

3, Why measurement accuracy must note effective range?

Because range will affect measuring accuracy, effective range of each model product is different for accurate measurement, even in 1m can not be accurate measurement.

4, Is blackbody necessary?

Not, blackbody is mainly correct temperature accuracy, some high end device no need blackbody, then temperature accuracy can be 0.3ºC in 6m too.

5, Why your thermal device price is higher than other company' thermal device?

Because thermal device quality is different, if used for same standard, then our price is very cheap.

This is why their thermal device do not show main performance details, such as accuracy details and effective range details.

6, Why you need select our product?

Because our product already tested and used by many customer. our product performance is very steady, many Station, Hospital, School, Enterprises that are using for our product. Also, some governments use our products as medical equipment.

TP210 Infrared Body Temperature Rapid Screening Thermal Camera Specifications:

Item TP210
Detector Data
Type Uncooled FPA
IR resolution 210×160
Spectral range 7.5~14μm
NETD/Sensitivity 70mK
Lens Data
FOV 35°× 27°
Minimum imaging distance 50cm
IFOV 1.7mrad
Focus Fixed focus.
Image Performance
Display 3.5 " inches color digital TFT display, rotatable, 640×480
Visual camera 300000 pixel, auto focus
Color palettes Spectra, iron red, black hot and white hot
Contrast/Brightness Auto/Manual
Measurement
Temperature range +20ºC~+45ºC,         -20 ºC~+330 ºC (manual switching)
Measurement accuracy ≤±0.5ºC in room ambient temperature;     ±2ºC or ±2%, whichever is greater
Effective range 1.5m
Measurement mode highest temperature, Center spot
Emissivity correction Adjustable emissivity from 0.01 to 1.0
Auto Hot Spot Tracking Yes
Alarm High temperature
Function settings Time
Measuring speed 21ms.
Image storage
Built-in memory Yes,
Storage media 4G
Image format JPEG
Interface
Power interface Yes
USB interface USB, Image transmission to computer, also battery can be charged
Power System
Battery type Lithium battery, rechargeable
Operating time 4h to 6h continuous working (room temperature)
Environment Parameters
Operating temperature range -20ºC~+50ºC (Ambient temperature room accurate temperature measurement)
Storage temperature range -40ºC~+70ºC
Humidity ≤95%(non-condensing)
Shock 2G(IEC60068-2-6)
Encapsulation IP54(IEC60529), 2-meter drop test
Physical data
Size 240mm×90mm×96mm
Weight 0.5kg,  gross weight 1.1kg for one set packing.
Packing
Standard Thermal Camera, battery charger, USB cable,  user manual, box case
Warranty 1 year

Note: * Product design and Technical information is subject to change without notice.

           ** Depending on the region of sale.


Product Image

TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 1
Img 1
TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 2
Img 2
TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 3
Img 3
TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 4
Img 4
TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 5
Img 5
TP210 Infrared Temperature Rapid Screening Thermal Imaging Camera 6
Img 6
