Usage: Gate valve of soft seal attaches seal atains seal funceion,using the force who come from the elastil suce board,turn on turn ff the medium,where the working pressure is≤1MPa,working temperture is≤8℃. It can be widely used in construction,food,medicine,chemical energy,water supply and drainage and other industries,used for regulation and interception on pipelines and equipment.
Usage: Gate valve of soft seal attaches seal atains seal funceion,using the force who come from the elastil suce board,turn on turn ff the medium,where the working pressure is≤1MPa,working temperture is≤8℃. They are widely used in architectonics, edibles, medicine, chenmical energy, applied and daining water industry, etc. It adjusts the water in piping and pipes it also does it in equipment.
Main Parts and Materials
Valve body/valve cover
Valve stem
Gate
Valve stem nut
Ductile iron
Stainless steel
Ductile iron + NBR
Brass, ductile iron
Performance Specification
Function And Specification
Z45X-10Q
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature 1-80℃
Applicable medium water
Z45X-16Q
Nominal pressure 1.6MPa
Test pressure (MPa)
Strength (water) 2.4
Seal (water) 1.8
Applicable temperature 1-80℃
Applicable medium water
