Purpose: The soft seal gate valve uses the slight deformation and compensation effect of the elastic gate plate when it is stressed to achieve a good sealing effect. The medium temperature is not higher than 80℃ during use. It can be widely used in construction, food, chemical energy, water supply and drainage and other industries for regulation and interception in pipelines and equipment.
Usage: Soft elastic damper forces sealed valve caused by the use of micro deformation compensation, compensation compensation, and to achieve good sealing effect using medium temperature does not exceed 80°℃, can be used in the construction, food processing, chemical energy, drainage and other industries, and the pipe and the closure as a means to regulate the use of equipment.
Main Parts and Materials
Valve body/valve cover
Valve stem
Gate
Packing
Ductile iron
Stainless steel
Ductile iron, nitrile rubber
EPDM rubber
Performance specification
Function And Specification
Z41X-10Q
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature 1~80℃
Applicable medium water
Z41X-16Q
Nominal pressure 1.6MPa
Test pressure (MPa)
Strength (water) 2.4
Seal (water) 1.8
Applicable temperature 1~80℃
Applicable medium water
