| Model: | Z944T/W-10/10Q |
|---|---|
| Brand: | - |
| Origin: | - |
| Category: | Industrial Supplies / Machine Hardware / Valves |
| Label: | valve |
| Price: |
-
|
| Min. Order: | - |
| Last Online:29 May, 2025 |
Usage:Turn on or turan of the pipelines where the nominal pressure is≤1.0MPa and the medium must be stem,water or oil,which can be used in fields of petroleum industry,chemical indemical industry,pharmaceutical industry and power industry.
Main Parts and Materials
Valve body/gate/valve cover
Valve stem
Middle mouth gasket
Valve stem nut
Gray cast iron, ductile iron
Carbon steel, brass, stainless steel
Xb300
Ductile iron, brass
Performance specification
Function And Specification
Z944W-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature ≤100℃
Applicable medium Oil
Z944T-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature ≤200℃
Applicable medium Water
