| Model: | FD-20T |
|---|---|
| Brand: | FEDA |
| Origin: | Made In China |
| Category: | Industrial Supplies / Metallurgy Machinery |
| Label: | - |
| Price: |
US $16850
/ set
|
| Min. Order: | 1 set |
| Last Online:06 Jun, 2025 |
1. Automatic feeding with adjustable brackets
2. Speed is adjustable for different products
3. 75mm hole diameter for SKD11/DC53 thread rolling dies
4. Max. Rolling pressure is about 200KN
5. It is easy to operate and maintain the machine
6. CE, ISO9001-2008
| Specification | ||
| Working diameter | 10-70mm | |
| Thread pitch | 1.0-6mm | |
| Thread length | In feed or Thru feed | |
| Spindle speed | 28/35/45/56rpm (variable speed) | |
| Outside diameter of rolling die | 178mm | |
| Inside diameter of rolling die | 75mm | |
| Thickness of rolling die | 140mm | |
| Feed stroke | 0-12mm | |
| Total machine power | 11KW | |
| Max rolling pressure | 20T | |
| Supply voltage | 380V 3P 50Hz | |
| Weight(reference) | 2800(KG) | |
| Package Dimension(L*W*H) | 1600*1510*1750mm | |
| Dimension(L*W*H) | 1550*1460*1650mm | |
Q1. Are you factory or trading company ?
A1. We are factory of manufacturing thread rolling machine and dies by ourselves.
Welcome to visit our factory, if possible.
Q2. What is the delivery time ?
A2. Usually 15-25 working days for machine, and 10-15 working days for dies.
Q3. What is the warranty time for machine?
A3. Usually 12 months from B/L date.
Q4. What is the payment term?
A4. T/T, Western Union, Money Gram, Alipay, PayPal.
50% as deposit, and 50% before shipping.
Q5. Is it possible to design and produce automatic loading & unloading devices?
A5. Yes, Engineer can design special auto feeding device according to your products.
But please provide the drawing of your products before that.
Q6. How will you solve problems that we face during using your machine?
A6. A. Please provide necessary videos and pictures that can show the problems, our engineers will check and give corresponding solutions.
B. Will arrange engineers to solve problems at the scene, if possible.
WhatsApp&Phone: +86-13312913043
QQ: 3833890347 Wechat: szfeda06
| Payment Terms: | TT |
|---|---|
