| Model: | AL-NP-5010 |
|---|---|
| Brand: | Aolong |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | xrf , spectrometer , fluorescence |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:16 Apr, 2024 |
Technical parameter of X-Ray Fluorescence Spectrometer
|
Model |
AL-NP-5010A |
|
|
Analysis principle |
Energy dispersive X-ray fluorescence analysis |
|
|
Element measuring range |
Any element from Na(11)~U(92) |
|
|
Min.measuring limit |
Cd/Hg/Br/Cr/Pb≤2ppm |
|
|
Sample shape |
Arbitrary size, any irregular shape |
|
|
Sample type |
Plastic/Metal/Film/Power/Liquid etc |
|
|
X ray tube |
Target material |
Mo |
|
|
Tube voltage |
5~50KV |
|
|
Tube current |
1~1000μA |
|
Sample exposure diameter |
2,5,8mm |
|
|
Detector |
Si-Pin or SDD detector,high speed pulse height analysis system |
|
|
High voltage generator |
Special HV generator for X fluorescence |
|
|
ADC |
2048 channels |
|
|
Filter |
6 filters are automatically selected and converted |
|
|
Sample observation |
200×color CCD camera |
|
|
Analysis software |
Patented software products,free upgrade for life |
|
|
Analysis method |
Theoretical α coefficient method,basic parameter method,empirical coefficient method |
|
|
Analysis time |
30~900 seconds,adjustable |
|
|
Operating system software |
WINDOWS XP |
|
|
Data processing |
Host |
PC business model |
|
system |
CPU |
≥2.8G |
|
|
Memory |
≥2g |
|
|
CD-ROM |
8×DVD |
|
|
Hard disk |
≥500G |
|
|
Display |
22''or 24'' LCD display |
|
Working environment |
Temperature 10~35℃，humidity 30~70% RH |
|
