| Model: | TK-BLGF |
|---|---|
| Brand: | TKA |
| Origin: | Made In China |
| Category: | Chemicals / Chemical Lab Supplies |
| Label: | Stainless Steel Reac , Hydrogenation Reacto , mixing machine |
| Price: |
US $35000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:26 Jun, 2023 |
Functional Use
The product is used in chemistry and chemical synthesis reactions or catalytic reactions at high temperatures, high pressures and negative pressures, where pressure, temperature, rotational speed and the addition of inert gases are to be measured simultaneously and where on-line sampling is to be achieved.
Application Examples
For hydrothermal synthesis of single crystals, CO2 reduction, CO2 reduction to methanol, CO2 reduction to methane CH4, reductive degradation of NOx, high-pressure photocatalytic degradation of formaldehyde, etc.
Catalytic reactions, Fischer-Tropsch reactions, hydrogenation reactions, polymerisation reactions, etc.
Model SPEC
|
Model |
Condition Size mm |
Volume |
Connection mode |
Intelligent safety valves |
Display accuracy |
|
BLGF2000ML |
350*350*550 |
2000ml |
Flange |
Yes |
±1ºC |
Technical Specifications and Configuration
|
Design volume |
2000ml |
|
Kettle body material |
Sapphire glass |
|
Working temperature |
≤300°C. |
|
Working pressur |
≤22.5Mpa (intelligent pressure relief) . |
|
Valve and connection material |
SU316L stainless stee |
|
With temperature control heating device and computer programmed heat transfer design |
|
|
With gas pass-in, pass-out function, feeding function, etc |
|
|
With on-line pressure display function |
|
|
Propulsion Magnetic Coupling Magnetic Stirring |
|
|
With condensation and recovery device |
|
|
With gas sampling device |
|
|
With liquid sampling device |
|
|
With liquid discharge device |
|
| Payment Terms: | T/T |
|---|---|
