| Model: | - |
|---|---|
| Brand: | Spark |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Other Electronic Components |
| Label: | high quality , fast delivery |
| Price: |
US $20
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:16 Aug, 2022 |
Product Description:
Silicon carbide heating element is a non-metallic high-temperature electric heating element. It is made of selected high-quality green silicon carbide as the main material, made into blanks, siliconized at high temperature, and recrystallized. It is the most popular economical heating element, capable of operating in hot and harsh environments.
Features as following:
1. use for furnace which temperature from 600C-1550ºC.
2. high strength and excellent shock resistance
3. heat source is free of noise and air pollution
4. anti-oxidization, anti- corrosion
5. easy to installation and maintenance
Specification:
|
Diameter |
Length of hot zone |
Length of cold zone |
Overall length |
Range of resistance |
|
8mm |
100-300mm |
60-200mm |
240-700mm |
2.1-8.6 ohms |
|
12mm |
100-400mm |
100-350mm |
300-1100mm |
0.8-5.8 ohms |
|
14mm |
100-500mm |
150-350mm |
400-1200 |
0.7-5.6 ohms |
|
16mm |
200-600mm |
200-350mm |
600-1300 |
0.7-4.4 ohms |
|
18mm |
200-800mm |
200-400mm |
600-1600 |
0.7-5.8 ohms |
|
20mm |
200-800mm |
250-600mm |
700-2000mm |
0.6-6.0 ohms |
|
25mm |
200-1200mm |
250-700mm |
700-2600mm |
0.4-5.0 ohms |
|
30mm |
300-2000mm |
250-800mm |
800-3600mm |
0.4-4.0 ohms |
|
35mm |
400-2000mm |
250-800mm |
900-3600mm |
0.5-3.6 ohms |
|
40mm |
500-2700mm |
250-800mm |
1000-4300mm |
0.5-3.4 ohms |
|
45mm |
500-3000mm |
250-750mm |
1000-4500mm |
0.3-3.0 ohms |
|
50mm |
600-2500mm |
300-750mm |
1200-4000mm |
0.3-2.5 ohms |
|
54mm |
600-2500mm |
300-750mm |
1200-4000mm |
0.3-3.0 ohms |
