Hardware

· 2*Gigabit Ethernet LAN

· 1*2.5Gbps Ethernet LAN

· 1*RJ11 for  Voice

· Dual band WiFi6: IEEE802.11 a/b/g/n/ac

· 1*Sim Card Slot

· 1*Power Supply

· Built-in  3/4/5G Antennas

· Built-in WiFi Antennas

· Buttons:

  Power, WPS, Reset

· LED Indicators:

  Power, 5G, 4G, , WiFi, WPS

​

5G/4G/3G

· 5G NR:

  Bands: N2/N5/N12/N41/N66/N71/N77/N78/N79

  MIMO 4x4, 256QAM

  Downlink up to 4Gbps

  Uplink up to 300Mbps

​

· LTE:

  FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B25/B26/B66/B71

  TDD: B38/B39/B40/B41/B42/B43/B46/B48

  LTE Cat 22

  MIMO 4*4, 256QAM
  Downlink up to 2.4Gbps
  Uplink up to 200Mbps

​

· WCDMA:

  B1/B2/B4/B5/B8

*The bands could be designed according to the operator bands

​

Dual Band WiFi

· IEEE802.11 a/b/g/b/ac

· 2.4Ghz + 5.8GHz

· MIMO  4X4

· Security: Open, WPA-PSK, WPA2-PSK,  WPA3-PSK

· 5G NR to WiFi Throughput: Up to 1Gbps

​

Features
· Voice

  VoIP, VoLTE, CSFB
· IPv4&IPv6
· DHCP Server, DHCP Relay, DNS, DDNS
· NAT, NAPT

· Routing

· VPN Passthrough

  PPTP/L2TP/IPSec Passthrough

· Data Usage Statistics

· Firewall:

  Port Forwarding, DMZ, URL/Domain Blocking, MAC/IP/Port filtering, White/Black List

· Device Management

  WEB, TR069

Environment

· Dimension: 160mm*86mm*215mm
· Net Weight 600 g

· Color: Black or White

· ±8KV ESD Protection
· Power Supply: 12V/2A
· Operation Range: -10° to 55°C
· Humidity:10-90% non-condensing

· Installation: Desktop
