| Model: | GS-1325 |
|---|---|
| Brand: | Gauss |
| Origin: | - |
| Category: | Industrial Supplies / Machinery / Engraving & Etching Machine |
| Label: | hsd cnc router , cnc router hsd , hsd spindle cnc |
| Price: |
US $4500
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:27 Feb, 2022 |
|
Model |
GS-1325 |
|
X .Y Axis working area |
1300X2500mm |
|
Z-Axis working area |
200mm |
|
Repeatability |
0.025(+/-mm) |
|
Max Cutting Speed |
25000mm/min |
|
Rapid Traverse |
30000mm/min |
|
Spindle power rate |
4.5KW(HSD air cooling) |
|
Spindle rotating speed |
0-24000rpm |
|
Command |
G code*.u00*.mmg*plt |
|
Work Mode |
Hybrid servo Motor |
|
Transmission |
X Y helical rack gear,Z ball screw |
|
Guide way |
Linear guide way(hiwin) |
|
Control system |
DSP |
|
Power |
AC380V/60Hz |
Suitable Industry:
Suitable for high-volume processing of non-ferrous metal sheet, Such as PVC board, acrylic, insulation materials, wood and composite panels such as sheet processing, cutting, slotting, engraving.
Performance Characteristics:
1.Imported Linear Guide way, Double-line Four-row Slider, Undertake Heavy-duty, Stable operation, High precision, Long lifetime, cutting with high precision
2.DSP controller works with USB flash, easy operation.
3.High-speed drive a stepper motor and driver, Y axis using a dual-motor drive, to make high-speed operation up to 20 meters above the blank line speed, with the cutting spindle can greatly enhance the carving is even more.
4.Software:compatible with type3/Artcam/Castmate / Ucancam a variety of CAD / CAM Design Software
Guarantee & aftersale service
Guarantee for one year, technical support by email or calling except Sunday or other holidays.
User-friendly English manual and Video CD for machine using and maintaining.
| Payment Terms: | TT / LC / DP |
|---|---|
