| Model: | GS-50W |
|---|---|
| Brand: | Gauss |
| Origin: | - |
| Category: | Industrial Supplies / Machinery / Engraving & Etching Machine |
| Label: | fiber laser engravin , fiber laser marking , fiber laser marker |
| Price: |
US $2200
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:27 Feb, 2022 |
|
Model |
GS-30F/50F |
|
Laser power |
30W/50W (Raycus Chinese) |
|
Laser Wavelength |
1065±10nm |
|
Divergence |
0.3mard |
|
Marking range |
0~110mm*110mm |
|
Minimum line width |
0.01mm |
|
Minimum character |
0.1mm |
|
Marking speed |
10000mm/s |
|
Marking depth |
0 ~0.5mm |
|
Control software |
JCZ (original) |
|
Engraving line speed |
7000mm/s |
|
Repeatability accuracy |
±0.001mm |
|
Power |
220V/50hz |
Product’s description:
1. Fiber laser marking machine is the 3thgeneration laser marking machine which is manufactured by the most advanced laser technology in current of the world.
2. The quality of laser beam is very good(near to the limit of diffraction,exporting TEM00 fundamental transverse mode, M2 near to 1,expanding angle of laser beam is only 1/4 of the diode laser marker),Therefore it is very suitable for delicate marking.
3. With high repeat frequency of the pulse,power output steadily,energy surge of single pulse is lower than 1%,BML-F can achieve high speed marking,and control the depth and shape of the facula .
4. The processing speed of GS-30F is 2-3 times than the traditional marking machine.
5. Air cooling,the size of the machine is very small.
6. Long life,ultralow power consumption,the conversion efficiency is more than 30%,the unit power of the machine is no more than 0.5kw!
| Payment Terms: | TT / LC / DP |
|---|---|
