| Model: | LX280T |
|---|---|
| Brand: | LONGXING |
| Origin: | Made In China |
| Category: | Industrial Supplies / Textile Machinery Parts |
| Label: | 80inch collar machin , jacquard machine , knitting machine |
| Price: |
US $12500
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:09 Aug, 2023 |
|
MAIN PARAMETER |
|
|
Gauge |
7G、9G、10G、12G、14G、16G(LX280T LXC280T)、18G( LXC280T) |
|
Maximum Knitting Width Inch(Cm) |
Carriage Combine 80 inch（203cm),Carriage Separate 35inch (89cm) |
|
Carriage System |
1+1Tandem or Combine 2 System |
|
Needle Selection System |
8 levels of selecting needle,SCE280T LX280T Directly selection system, LXC280T 3-WAY |
|
Racking |
Servo motor,LX280T And SCE280T Max 1 inch, LXC280T Max 2 inch |
|
Take Down |
128 option, Rubber roller(Optional) Driving By step motor And Main Roller Driving By AC Motor |
|
Yarn Feeder |
Two roller yarn feeder,Left And Right |
|
Yarn Carrier |
LX280T And SCE280T 3 Rail 6+6, LXC280T 4 Rail 8+8; Automatic Stop |
|
Carriage Driving Device |
Servo motor, Timing belt |
|
Knitting Speed【1】 |
128 levels of speed. Max 1.4m/s |
|
Date Input |
USB2.0, RJ45(Optional) 128M memory |
|
Safety Equipment |
Emergency stop switch; emergency power off equipment; abnormal stop and alarm with light and sound |
|
Power Consumption【2】 |
1 phase AC 220V, 50/60HZ, electricity consumption 1 kw |
【1】Depends on the gauge, yarn and the pattern etc.
【2】The actual electricity consumption is far below the marked value, depends on the gauge and the working condition.
|
MACHINE MODEL |
BOUNDARY DIMENSION（mm） |
PACKAGE DIMENSION（mm） |
NET WEIGHT（KG） |
GROSS WEIGHT（KG） |
|
LENGTH×WIDTH×HEIGHT（A×B×C） |
LENGTH×WIDTH×HEIGHT |
|||
|
LX280T |
3715×815×1850 |
3900×1050×1820 |
940 |
1190 |
|
SCE280T |
3715×815×1850 |
3900×1050×1820 |
940 |
1190 |
|
LXC280T |
3715×815×1850 |
3900×1050×1820 |
1450 |
1700 |
Because of the improvement and development of products, we reserve the right to change technical data. Please contact us for the latest information.
