Handheld Ultrasonic Flowmeter TDS-100H Bracket Transducer DN20mm-DN700mm

Model:TDS-100H
Brand:AERMANDA
Origin:Made In China
Category:Electronics & Electricity / Electronic Instrument / Air & Gas Flowmeter
Label:Ultrasonic Flowmeter , flowmeter , bracket transducer
Price: US $415 / Piece
Min. Order:1 Piece
Inquire Now Add to Basket

Member Information

Detail

Shenzhen Aermanda Technology Co.,Ltd.

Biz MemberGuang Dong - China
Live Chat:
Last Online:14 Jan, 2022

Product Description

Linearity

0.5%

Repeatability

0.2%

Accuracy

±1% of reading at rates>0.6 ft/s. ±0.5% with on-site calibration

Response Time

0-999 seconds, user-configurable

Velocity

±0.03 ~ ±105 ft/s (±0.01 ~ ±30 m/s), bi-directional

Pipe Size

(15 ~ 6,000mm)

Rate Units

Meter, Feet, Cubic Meter, Liter, Cubic Feet, USA Gallon, Imperial Gallon, Oil Barrel, USA Liquid Barrel, Imperial Liquid Barrel, Million USA Gallons. User configurable.

Totaliser

7-digit totals for net, positive and negative flow

Liquid Types

Virtually all liquids

Security

Setup lockout. Access code needed for unlocking

Display

4x16 English letters

Communication Interface

RS-232C, baud-rate: from 75 to 115,200 bps. Protocol made by the manufacturer. User protocols can be made on enquiry.

Transducers

Model M1 for standard, other 3 models for optional

Transducer Cable

Standard 2x30? (10m), optional 2x1,500? (500m)

Power Supply

3 AAA Ni-H built-in batteries. When fully charged it will last over 10 hours of operation.

90-230VAC for the charger

Data Logger

Built-in data logger can store over 2,000 lines of data

Manual Totalizer

7-digit press-key-to-go totalizer for calibration

Housing Material

ABS. Aluminum alloy protective case

Case Size

3.9"x2.6"x0.8" (100x66x20mm)

Handset Weight

1.2 lbs (514g) with batteries



Transducer

Standard S2 type

Standard M2 type

Standard L2 type

 Standard HS type

 Standard HM type

Suitable pipe diameter

DN15-DN100mm

DN50-DN700mm

DN300-DN6000mm

 DN20-DNDN100mm

 DN50-DN700mm

Fluid temperature

0°c-160°c

0°c-160°c

0°c-160°c

 0°c-160°c

 0°c-160°c

Outer size

45×30×30mm

60×45×45

80×70×55





Weight

75g

250g

528g







Standard packing:

1 x TDS-100H host

Standard HS Transducer

Standard HM Transducer

2 x 5m Signal Cable

2 x Fastening Chains

1 xData cable

1 x Charger

1 x 5m Ruler

1 x Empty plastic bottle (for loading gel)

1 x English Instruction Manual

1 x Carrying Case



If you need other transducer, please contact us.
