| Model: | - |
|---|---|
| Brand: | BOATAR |
| Origin: | Made In China |
| Category: | Transportation / Logistics / Lifting Systems |
| Label: | crane hook , hoist hook , cargo hook |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:19 May, 2023 |
| MODEL | CAPACITY
（TON） |
MAIN DIMENSION（MM） | WEIGHT（KG） | |||||||
| H | H1 | L | L1 | D1 | D2 | Φ | D | |||
| FD2T | 2 | 420 | 380 | 260 | 155 | 210 | 170 | 7.2 | 220 | 15 |
| FD3T | 3 | 460 | 410 | 260 | 155 | 210 | 170 | 11 | 220 | 15 |
| FD5T | 5 | 480 | 420 | 300 | 185 | 210 | 170 | 13 | 220 | 25 |
| FD10T | 10 | 620 | 550 | 350 | 2240 | 260 | 210 | 15 | 270 | 50 |
| FD16T | 16 | 740 | 650 | 350 | 230 | 330 | 280 | 17.5 | 3550 | 104 |
| FD20T | 20 | 850 | 800 | 450 | 290 | 400 | 350 | 19.5 | 420 | 154 |
| FD32T | 32 | 1020 | 980 | 470 | 325 | 465 | 400 | 24-26 | 485 | 260 |
| FD16T-S | 16 | 670 | 580 | 350 | 230 | 330 | 280 | 17.5 | 355 | 94 |
| FD20T-S | 20 | 760 | 680 | 394 | 265 | 400 | 350 | 19.5/21.5 | 420 |
145
|
customize acceptable: single pulley& double pulley& round appearance& irregular appearance.
this series hook is widely applicable in workshop, warehouse, port and etc. but strictly forbit to use in situation such as explosive, corrosive, acied, plating and etc.
feature:
made of high quality steel, forged hook, high strengh, safe, reliable and durable;
compact structure, good appearance;
high-thrust bearing accembly, light and flexible;
using precision cast steel pulley which can protect wire rope well, long life-span;
high efficiency with smoonth and silent running, low noise;
suit for high lifting capacity and heavy duty class.
