| Model: | BE-Series |
|---|---|
| Brand: | DGBELL |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | nail penetration , battery safety test , testing equipment |
| Price: |
US $15000
/ set
|
| Min. Order: | 1 set |
| Live Chat: |  | Last Online:27 Dec, 2019 |
Standard Compliance
1 GB/T 18332.2-2001 Nickle-Metal Hydride Batteries of Electric Road Vehicles
2 QC/T 743 Lithium-ion Batteries for Electric Vehicles
3 QC/T 744 Nickle-Metal Hydride Batteries for Electric Vehicles
4 Tests complied with International standards (ISO/IEC/SAE/JEVA/CEN etc), internal standard association and 863 program covering hydride electric vehicles relating to electric vehicle lithium-ion battery;
5 QB/T 2947.3-2008 Electric Bicycles-Cell or Battery and Chargers Part 3: Li-ion Batteries and Chargers
6 DB12/T246-2005 Electric Bicycles-Cell or Battery and Charger Standard Test;
7. GB 19521.11-2005 Safety Code for Inspection of Hazardous Properties for Dangerous Goods of Lithium Batteries;
Specification
|
Tester Model |
Test Zone (MM) |
Overall Dimension (MM) |
|
BE-9002D-2T |
200X200X200 |
W750XD650XH1800 |
|
BE-9002D-5T |
600X600X600 |
W1000XD900X2200 |
|
BE-AP-9002D |
800X800X800 |
W3000XD1200XH1300 |
|
BE-AP-9002T |
1000X1000X1000 |
W3300XD1500XH1500 |
Technical Parameters
|
Auxiliary Function |
Voltage, temperature sampling, camera monitoring system. Fire-extinguishing system, smoke evacuation & filtering system |
|
|
Penetration Speed |
0 ~ 80mm/s(controllable), 200 mm/s can be customized |
|
|
Test Zone(mm) |
200X200X200MM,600X600X600MM,800X800X800MM,1000X1000X1000MM (Available to customize) |
|
|
Overall Dimension |
Subject to actual design and manufacture |
|
|
Optional Parameters |
Voltage Range |
0—10V,0--100V,0—1000V |
|
Temperature Sampling Range |
0 ~ 1200℃ |
|
|
Voltage, Temperature Accuracy |
±1%FS |
|
|
Voltage Resolution |
1mV |
|
|
Temperature Resolution |
0.1℃ |
|
|
Standard Parameter P Par |
Speed |
0 ~ 80mm/s(Controllable), 200 mm/s (Available to customize) |
|
Nail Travel |
0—1000MM to select |
|
|
Structure |
Vertical & horizontal (select according to actual size) |
|
|
High Temperature Nail Regulation |
Diameter φ3mm~φ8mm |
|
|
Nail Penetration Method |
Horizontal, vertical |
|
|
Nail Deformation |
No (Computerize can be customized) |
|
|
Nail Remaining Time |
0~99 H 99M 99S |
|
|
Driven Method |
Hydraulic |
|
|
Nail Penetration Speed |
±0.1MM/S |
|
|
Force Accuracy |
±1% |
|
|
Structure |
Chamber |
Independent vertical & horizontal test machine and control system |
|
Communication |
No (computerize can be customized) |
|
|
High temperature Nail |
Diameter φ3mm~φ8mm (available to customize) |
|
|
Data Acquisition Module |
Independent remote sampling, multi-voltage, temperature, current acquisition channel (optional) |
|
|
Channel Quantity Configuration |
2-Channel, 4-Channel, 8-Channel, multi-data acquisition system (optional) |
|
|
Camera Monitoring System |
Test zone installed with high definition camera monitoring system in remote control with explosion-proof (optional). |
|
|
Standard Configuration |
Nail Penetration Machine/1 set, control cabinet/1 set, diameter φ3mm~φ8mm, high temperature nail/1 set |
|
|
Test Fixture |
Customize according to actual size |
|
|
Power Source |
AC380V 50HZ 3P5W |
|
|
Working Environment |
0℃~45℃ |
|
Features
Complied with previous version QC 743:
High temperature steel nail with its diameter at φ3mm~φ8mm penetrate at a speed at 10mm/s~40mm/s into at least 3 battery plates by vertical direction (nail remains into the battery cell);
Complied with newly version QC 743:
High temperature steel nail (angle of nail point at 60°and clear surface without rust and grease) with its diameter at φ20mm~φ30 mm penetrate at a speed at 10mm/s~40mm/s into at least 3 battery plates by vertical direction (nail remains into the battery cell and keep observation by 1 hour);
