Hot - Dip Ga anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine

Model:TW-CBT300
Brand:TECHWELL
Origin:Made In China
Category:Construction & Decoration / Shaped Building Material
Label:Cable Tray , Cable Ladder , Cable Profile
Price: US $32000 / set
Min. Order:1 set
Inquire Now Add to Basket

Member Information

Detail

Wuxi Techwell Machinery Co.,Ltd

Free MemberJiang Su - China
Live Chat:Last Online:01 Aug, 2016

Product Description

Hot - Dip Ga anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine

Product Details:

Place of Origin: China

Certification: CE

Packaging Details: Standard packing

Delivery Time: 60 working days

Supply Ability: 20 sets/month

Main Specifications:

  • Material: Q235 cold rolled strip or Hot-dip Ga anizing stee strip
  • Material Thickness:2.0mm,
  • Material Width: 400mm
  • Rolling Product Length: 0 limited, 0-any mm
  • Rolled Product Straightness Error: 1-1.5mm/1500mm
  • Rolling Product Angle Error: ≤±1.5/1000mm
  • Motors Explosion-proof Rating: ExdllCT4
  • Motor Protection: IP55
  • Total Installed Capacity Power: about 31.4 KW
  • Forming Station of Cable Tray Roll Forming Machine: 16 Steps
  • Speed of Line: 0-10m/min.
  • Weight of machine: about 11.5 Ton

Working Flow

Auoto Decoiler – Tranporting & 9 Rollers Leveling – Servo Feeding -- 100 Ton Punching machine -- Oriented – Transportation – 8 Holes Punching -- Main Forming -- Cutting -- Run out table




Product Image

Hot - Dip Ga  anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine 1
Img 1
Hot - Dip Ga  anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine 2
Img 2
Hot - Dip Ga  anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine 3
Img 3
Hot - Dip Ga  anizing Steel Strip Cable Profile, Cable Tray Roll Forming Machine 4
Img 4
