DIAMOND CUTTING TOOLS
1.DIAMOND CUTTING DISC
This product is used to make cutting and grooving on ceramic tiles on automatic and manual cutting machines. There are four normal working modes: manual single-blade full cutting, automatic single-blade full cutting, automatic two-blade full cutting and pre-cutting, chamfering and full cutting. Our diamond cutting disc are approved for their high working speed, fine and precise cutting effect, low tiles edge-breaking ratio and long working lifetime.
1.1.WHOLE SINTERED DIAMOND CUTTING DISC
This product is used to make full cutting, half-cutting or grooving on polished porcelain tiles, wearable ceramic tiles, rustic tiles, glaze floor and wall tiles. It can be used by single blade and multi blades. Our whole sintered diamond cutting discs are approved for their good sharpness, smooth and flat cutting slots and no chipping. This product is normally used on single-head or two-head automatic cutting machines and manual cutting machines.
Other specs are available upon request.
|
CODE |
OUTER DIAMETER |
THICKNESS (mm) |
HEIGHT (mm) |
ARBOR (mm) |
GRIT |
|
|
INCHES |
METRIC (mm) |
|||||
|
HRT/HST 105 |
4 |
105 |
1.8 |
8 |
20 |
D64 D76 D91 D107 D126 D151 D181 D213 D252 D301 D427 |
|
HRT/HST 110 |
4⅓ |
110 |
1.8 |
7/10 |
20 |
|
|
HRT/HST 114 |
4.5 |
114 |
1.8 |
7/10 |
20 |
|
|
HRT/HST 125 |
5 |
125 |
1.8/2.0 |
7/10 |
20 |
|
|
HRT/HST 150 |
6 |
150 |
2.0 |
7/10 |
22.23 |
|
|
HRT/HST 180 |
7 |
180 |
2.0/2.2 |
7/10 |
22.23 |
|
|
HRT/HST 200 |
8 |
200 |
2.0/2.2 |
7/10 |
22.23 |
|
|
HRT/HST 230 |
9 |
230 |
2.2/2.4 |
7/10 |
22.23 |
|
|
HRT/HST 250 |
10 |
250 |
2.0/2.2/2.4 |
9/10 |
60 |
|
|
HRT 300 |
12 |
300 |
2.0/2.2/2.4 |
9/10 |
60 |
|
|
HRT 350 |
14 |
350 |
2.0/2.2/2.4/2.8 |
8/10 |
50/60 |
|
|
HRT 400 |
16 |
400 |
2.2/2.4 |
10 |
75 |
|
1.2. WELDED DIAMOND CUTTING DISC
This product is used to make cutting on polished porcelain tiles, wearable ceramic tiles, rustic tiles, glaze floor and wall tiles. It can be used by single blade and multi blades. Our welded diamond cutting discs are approved for their good sharpness, smooth and flat cutting slots, no chipping and long working lifetime. This product is normally used on single-head or two-head automatic cutting machines and manual cutting machines.
|
CODE |
OUTER DIAMETER |
THICKNESS (mm) |
HEIGHT (mm) |
ARBOR (mm) |
GRIT |
|
|
INCHES |
METRIC (mm) |
|||||
|
WST180 |
7 |
180 |
1.8/2.0 |
10 |
60 |
D126 D151 D181 D213 D252 D301 D427 |
|
WST200 |
8 |
200 |
1.8/2.0 |
10 |
60 |
|
|
WST250 |
10 |
250 |
1.8/2.0/2.2/2.4 |
9/10 |
60 |
|
|
WST300 |
12 |
300 |
1.8/2.0/2.2/2.4 |
9/10 |
60 |
|
|
WST350 |
14 |
350 |
2.4/2.6/2.8 |
9/10 |
50/60 |
|
|
WST400 |
16 |
400 |
2.4/2.6/2.8 |
9/10 |
50/60 |
|
|
WST450 |
18 |
450 |
2.6/3.0 |
9/10 |
50/75 |
|
1.3. DIAMOND GROOVING DISC
This product is used to make grooving on polished porcelain tiles, wearable ceramic tiles, rustic tiles, glaze floor and wall tiles. It can be used by single blade and multi blades. Our welded diamond cutting discs are approved for their good sharpness, straight grooving effect, no chipping, long working lifetime and flat cutting bottom.
This product is normally used on single-head continuous cutting machines and manual cutting machines.
|
CODE |
OUTER DIAMETER |
THICKNESS (mm) |
HEIGHT (mm) |
ARBOR (mm) |
GRIT |
|
|
INCHES |
METRIC (mm) |
|||||
|
WST115 |
4.5 |
115 |
4.0/5.0 |
7 |
20 |
D107 D126 D151 D181 |
|
WST150 |
6 |
150 |
5.0/6.0/10 |
7 |
30/32 |
|
|
WST200 |
8 |
200 |
5.0/6.0 |
7 |
30/32 |
|
|
WST250 |
10 |
250 |
3.0/3.8/4.0/4.5/5/10/15/20 |
7 |
60 |
|
|
WST300 |
12 |
300 |
3.0/3.8/4.0/4.8/5/6/6.5/10/15/20 |
7 |
60 |
|
1.4.DIAMOND CHAMFERING DISC
This product is used to make chamfering on polished porcelain tiles, wearable ceramic tiles, rustic tiles, glaze floor and wall tiles. It can be used by single blade and multi blades. Our diamond chamfering discs are approved for their good sharpness, smooth chamfering effect, no chipping and long working lifetime. It is used on three-head continuous cutting machines or manual cutting machines: the first head is for pre-cutting, the second head is for chamfering and the third head is for full cutting.
|
CODE |
OUTER DIAMETER |
THICKNESS (mm) |
HEIGHT (mm) |
ARBOR (mm) |
GRIT |
|
|
INCHES |
METRIC (mm) |
|||||
|
WST150 |
6 |
150 |
4.0/5.0/6.0/ |
7 |
30/32 |
D91 D107 D126 D151 D181
|
|
WST200 |
8 |
200 |
5.0/6.0 |
7 |
30/32 |
|
|
WST250 |
10 |
250 |
4.0/5.0/6.0/6.5 |
7 |
60 |
|
|
WST300 |
12 |
300 |
4.0/5.0/6.0/6.5 |
7 |
60 |
|
Monte-Bianco was established in 2000. With more than 10 years of constantly dedicated research and development of super-hard material applications, now we are one of the leading ISO 9001 and ISO 14000 certified companies in the industry of Chinese super-hard material applications. Up till now our brand Monte-Bianco has been approved and trusted by customers from more than 60 countries and regions.main product is diamond wire saw，saw blade，diamond fickert，diamond saw blade，cutting disc，grinding brush
