Self service ticketing print touch kiosk with card reader

Model:NT-8006
Brand:Netoptouch or OEM
Origin:Made In China
Category:Consumer Electronics & Lighting / Commerce & Finance Electronics / Finance Electronics
Label:ticket printer kiosk , ticket kiosk design , payment ticket kiosk
Price: US $850 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Shenzhen Netoptouch Technology CO.,Ltd

Biz MemberGuang Dong - China
Live Chat:
点击这里给我发消息Last Online:11 May, 2021

Product Description

Self service ticketing print touch kiosk with card reader



1. Interactive Infrared touch screen kiosk

2. High resolution and super light transmittance

3. Waterproof, dustproof, explorsion proof....

4. Support WIFI or wirelss networkd

5. Industrial open frame TFT LCD touch monitor integrated

6. 1.5mm or 2mm cold rolled steel enclosure

7. It can be install memory card, thermal printer, WIFI, GPRS, UPS ...

8. Upgradable functions available ,

9. Customize available

10.Can be compatible with photo printer, thermal printer,A4 printer successfully.

11.With high definite camera,

12.bluetooth connection



 Technology Specification:



LCD Display

TFT LCD 17”19‘’22‘’

Resolution

1280*1028

Contrast Ratio

300:1

Color Resolution

16.7M

Brightness

300cd/m2

DC Adapter

DC12V 5A

Touch Technology

Anti-Dust SAW Touch Screen Kit

Resolution

4096*4096

Deviation of Error

1mm

Light Transmission

92%~95%

Response Time

Less than 8ms

Touch Activation Force

Less than 100g(adjust allowed)

Durability

Scratch-free; More than 50,000,000 touches in one location without failure.

Surface Hardness

Mohs’ hardness rating of 7

Controller Interface

USB and RS232

PC Specification

Mini PC

CPU

Intel J1900 2.0GHZ

RAM

DDR3 4GB

Storage

120GB SSD

Display Chipset

NVIDIA ION 9400M GPU

Video

MDHI 1080P

Internal WiFi

802.11 b/g/n

Ports

USB, HDMI, VGA, LAN, SD-MMC-MS-MSPRO, sound input, sound output

Power Consumption

30 W

Operating System

Windows 7/Linux Ubuntu

System

User Interface

photo kiosk solution

Remote Management

remote management solution

Standard Components

Wireless

802.11 b/g/n WiFi and antenna

Camera

Mini camera

Printer

60mm thermal printer

Card Device

2.5” multi-card reader





External Device

External digital photo printer

Physical Specification

Kiosk shell material

1.5mm cold rolled steel

Color

optional

Fan

2 x 12V fans

Audio | Speakers

2 x 15W Speakers, 1 x 30W Amplifier

Ports | Slots

Power input | Power switch | PC switch | USB | LAN | Volume control

Power Supply

International 110–240 AC power

Operate environment

Temperature: +5°C ~ +50°C | Humidity: 0% ~ 80%

Export packaing: foam, carton, wooden case

Certification:CE&FCC&RoHS

Warranty: 1 year

MOQ: 1 piece



Transport: By ocean shipping, air transport, DHL, UPS..etc

Payment: T/T, L/C, Western Union



Delivery, Usually 21days for shipping



To fully realize the ROI potential of self-service ticketing, it's commonplace to require a very robust solution

that can function reliably - both indoors and out.

Further, higher levels of custom peripheral integration are often required in ticketing and check-in kiosk solutions

 (ex.- passport readers, cash acceptors, assistance devices for disabled clients).

KIOSK stands alone in these combined capabilities, and has provided a full complement of custom and standard solutions .






Price Terms:EXW price
Payment Terms:T/T, L/C, Western Union,Escrow,paypal
Packing:Bubble Foam, carton, wooden case,Anti static bag
Lead Time:15 days after receive the deposit
Standards Certificate:CE&FCC&RoHS
