Description: JACI MOULD is very professional in thin wall food container moulds manufacturing.the container wall thickness can be 0.4mmto 0.55mm for multi-cavities,we can also make thin wall container mould suitable for label, in which the prefabricated plastic label is positioned directly into the mould by a special handling robot. Guarantee the moulds life 1million,using steel S136 with hardness 42-48 after vacuum heating treatment.
in-mould-label mould, Hardened steel enriched with chromium enabling fast cycling, Mould long life and reliability.Long-lasting final product high-quality for large production



Product name :1Liter IML container MOULD
product introducion:%100 leakage proof container prodce with IML (in mould labeling) technology.
I-M-L Mould Application:.Food package IML system
Injection mold/mould Cavities:4cavity
Mould steel:Sweden S136 Pretreat52-55HRC
Avaliable mould base:LKM DIN1.2312
Standard: CopyDME,HASCO
Hot runner:4point Yudo hot runner valve system
Life time:>:5M time.
Delivery time:60days
Injection cycle time:6seconds
The country of mould'client:South Africa
