| Model: | LC-MI1201ET-5R |
|---|---|
| Brand: | Anrecson |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Other Electrical & Electronic |
| Label: | industrial monitor , touchscreen LCD , embedded mount |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:20 Jun, 2016 |
|
Specification |
|
|
12.1"Touch Industrial Monitor |
|
|
Mode Name |
LC-MI1201ET-5R |
|
Screen Size |
12.1" |
|
Active Display Area (mm) |
261.12mm(H)×163.2mm(V) |
|
Display Mode |
16:10 |
|
LCD Type |
TFT-LCD |
|
Resolution |
1280*800 |
|
Display Color |
16.7M |
|
Pixel Pitch(mm) |
0.204(H)×0.204(V) |
|
Brightness(nits) |
450cd/m² |
|
Contrast Ratio |
350:1 |
|
Viewing Angle |
130(H) /115(V) |
|
Response Time |
12 ms |
|
Backlight |
2 CCFL |
|
Interface |
D-Sub15 pin(VGA),DVI,HDMI |
|
Power |
DC12V 4A 50HZ/60HZ/70HZ |
|
Power Consumption |
≤25W (Max) |
|
Plug & Play |
DDC 1/2B |
|
OSD Control |
Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language.. |
|
MENU |
Chinese/English(other languages supported) |
|
Mount Method |
|
|
Mounting |
Embedded Mount |
|
Optional Mounting Way |
VESA 75mm/100mm |
|
Touch Type |
|
|
TouchScreen Type |
Resistive(5-wire) |
|
TouchScreen interface |
Serial (RS232) or USB(B) |
|
Certificate Approval |
CE,RoHS,CCC,FCC,ISO9001 |
|
Warranty |
1.5 years |
|
Application |
|
|
ATM/ Kiosk/Transportation/ Industrial Automation/Medical Treatment |
|
