QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine

Model:QGF-100
Brand:LONGWAY
Origin:Made In China
Category:Industrial Supplies / Food, Beverage & Cereal Machine
Label:5 GALLON FILLING , GALLON BOTTLE MACHIN , 20L FILLING MACHINE
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Product Description

Product Description

Specifications

5 Gallon Water Production Line
60-1200BPH barreled filling
Stainless steel 304 material
CE/ ISO certificate

5 Gallon Water Production Line ( 5 Gallon Water Filling Machine )

Introduction of 5 gallon water filling machine:

Longway automatic integrated barreled 5 or 3 gallon barreled drinking water production line, now we have 80 barrels per hour, 150 barrels per hour, 300barrels per hour and larger capacities until to 2000bph capacity model production line and machines.

The one unit main machine includes the washer, filler and capper.

Rinsing process: alkaline water → acid water→ sterilized water, to make sure the barrel inside is sanitary.

The entire control system is PC, with the safe device for interlock, signal and slef-detection.

Features of 5 Gallon Water Production Line:

1. 5 gallon barreled water filling, washing and capping integrated machine

2. 80-2000bph barreled water filling capacity

3. Automatic integrated barreled water filling unit

4. Stainless steel 304 material

5. Mitsubish, Omron, Schneider electric components/ Airtac pneumatic

6. CE/ISO certificate

Technical Parameter of Longway 5 Gallon Water Filling Machine :

Model

QGF-100

QGF-240

QGF-300

QGF-450

QGF-600

QGF-900

QGF-1200

Filling heads

1

2

2

3

4

6

8

Volume(Gallon)

3&5

3&5

3&5

3&5

3&5

3&5

3&5

Barrel size(mm)

270*490

270*490

270*490

270*490

270*490

270*490

270*490

Capacity(b/h)

60-100

100-240

250-300

400-450

600-800

800-900

1000-1200

Gas pressure(Mpa)

0.4-0.6

0.4-0.6

0.4-0.6

0.4-0.6

0.6

0.6

0.6

Gas consumption(m³/min)

0.37

0.37

0.6

0.8

1

1.5

1.8

Motor power(kw)

1.38

1.75

3.8

3.8

7.5

9.75

13.5

Related Voltage(V)

380V/HZ

380V/HZ

380V/HZ

380V/HZ

380V/HZ

380V/HZ

380V/HZ

Weight(kg)

680

800

1500

2100

3000

3500

450









Product Image

QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 1
Img 1
QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 2
Img 2
QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 3
Img 3
QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 4
Img 4
QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 5
Img 5
QGF-100 5 Gallon Water Bottling Machine Washing Filling Capping Machine 6
Img 6
