Soda Pop/Soda Water/Filling Machine DCGF32-32-10
Product Description
The series equipment is used for filling carbonated drink in bottles made of polyester or plastic.
★ Characteristics:
- the machine can carry out the three functions of bottle washing, filling, capping.
- the advanced programmed controller (PLC) is adopted to control the machine running automatically.
- the bottle entry section adopts air conveyor system.
- the bottle exit section adopts belt conveyor system, which can adjust the speed.
- the machine are of high quality,the key spare-parts are made by famous producer
|
|
★ main technical specification |
Model
|
DCGF 14-12-5 |
DCGF 16-12-6 |
DCGF 18-18-6 |
DCGF 24-24-8 |
DCGF 32-32-10 |
ProductionCapacity(500 ml/b/h)
|
2000-2500 |
2000-2500 |
3000-5000 |
6000-8000 |
8000-10000 |
Washing heads
|
14 |
16 |
18 |
24 |
32 |
Filling heads
|
12 |
12 |
18 |
24 |
32 |
Capping heads
|
5 |
6 |
6 |
8 |
10 |
Suited bottle |
PET round or square bottle |
Diameter of bottle |
φ50-φ90 |
Height of bottle |
150-310 |
Pneumatic pressure(Mpa) |
0.3-0.7 |
Washing medium |
sterile water |
Washing pressure |
0.25 |
Total power (KW) |
3.13 |
3.13 |
3.84 |
3.84 |
5.6 |
Dimension (mm) |
2250x1600x2100 |
2250x1640x2100 |
2430x1800x2100 |
3050x2060x2100 |
4050x2300x2100 |
Total weight ( kg) |
2200 |
2500 |
3000 |
4000 |
5000 |
|
Product Image
