| Model: | XTB30/XTB50 |
|---|---|
| Brand: | ZOWELL |
| Origin: | Made In China |
| Category: | Transportation / Logistics / Forklifts, Pallet Trucks |
| Label: | towing tractor , tow head , forklift truck |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:27 Nov, 2017 |
Features of3Ton-5Ton Tow Tractor
1. Regenerative braking function
2. CURTIS electronic controller
3. Germany Frei handle
4. Side battery roll-out system,making itvery convenient for battery replacement.
5. Emergency reversing device in the handle provides improved operating safety.
6. Emergency power disconnect switch.
7. Braking applied with handle upright and horizontal position, increasing the safety of the truck.
Technical Data of 3Ton-5Ton Tow Tractor
|
Identification |
Product model |
|
XTB30 |
XTB50 |
|
|
Power supply |
|
Electric |
|||
|
Operating type |
|
Pedestrian |
|||
|
Lifting capacity |
Kg |
≤2500kg |
≤4500kg |
||
|
Towing capacity |
Kg |
≤3000kg |
≤5000kg |
||
|
Draw-bar-pull at the hook |
Kg |
97.6kg |
195kg |
||
|
Load distance |
X mm |
112 |
|||
|
Wheelbase |
Y mm |
999 |
|||
|
|
Weight (without battery) |
Kg |
435 |
||
|
Wheel |
Tyres |
|
Polyurethane |
||
|
Tyre size drive end |
mm |
Φ230x75 |
|||
|
Type size load end |
mm |
Φ150x60 |
|||
|
Balancing wheel size |
mm |
Φ100x50 |
|||
|
Wheels number (x=drive wheel) drive end/load end |
|
1x-2/2 |
|||
|
Tread width drive end |
mm |
400 |
|||
|
Tread width load end |
mm |
568 |
|||
|
Dimensions |
Total height |
h1 mm |
1400 |
||
|
Lift height |
h3 mm |
170 |
|||
|
Height of handle in drive position (Max/Min) |
h6 mm |
1350/800 |
|||
|
Overall length |
L1 mm |
1227 |
|||
|
Length to face of forks |
L2 mm |
565 |
|||
|
Overall width |
b1 mm |
850 |
|||
|
Min. ground clearance |
m mm |
70 |
|||
|
Turning radius |
Wa mm |
1200 |
|||
|
Performance |
Travel speed loaded/unloaded |
km/h |
5.2/6 |
4.8/5.6 |
|
|
Lift speed loaded/unloaded |
mm/s |
40/50 |
|||
|
Lowering speed loaded/unloaded |
mm/s |
50/40 |
|||
|
Max gradeability loaded/unloaded |
% |
8/15 |
|||
|
Service brake |
|
Electromagnetic |
|||
|
Electric Motor |
Drive motor rating |
kW |
AC1.5，DC1.1 |
AC2.0，DC2.2 |
|
|
Lift motor rating |
kW |
2.2 |
|||
|
Battery voltage / nominal capacity |
V/Ah |
24/210 |
|||
|
Battery weight |
Kg |
195 |
|||
|
Others |
Type of drive control |
|
MOSFET Control |
||
|
Noise level at operator’s ear |
dB(A) |
<70 |
|||
