Full Servo pull up baby diapers machine

Model:JWC-LLK400-SV
Brand:JWC
Origin:Made In China
Category:Industrial Supplies / Paper Machinery
Label:baby diaper machine , pull up baby diaper , TRAINING DIAPER
Price: US $2170000 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Jiangsu JWC Machinery co.Ltd

Biz MemberJiang Su - China
Live Chat:点击这里给我发消息Last Online:14 Oct, 2020

Product Description


Specifications:Technical Parameters

1: Model: JWC-LLK400-SV
2:Power Source: Three Phase:380V 50HZ
3: Installation Power: 320KW(excluding glue applicators, air compressor, the final power shall be confirmed after completion)
4: Product Sizes Medium and large sizes (only changing crotch size instead of changing waist size)
5: Production Speed: 350 pcs/min (Medium)
6:Qualification Rate≥96%(excluding glue applicators, wastes caused by splicing raw materials)
7:Overall Size(L×W×H):38m×12m×4.5m(for reference)
8:Machine Process Direction (raw material→ products)right to left(facing machine)

Advantages:Product Structure
1: Core layer structure: big cotton core adopts alien continuous stripping to shape and small cotton core adopts direct buckle the forming. Big cotton core and small cotton core are pressed solid after wrapping by tissues.
2. Acquisition layer slitting adopts scraping. (Scraping length is controlled by servo motors.)
3. Top sheets are composed of side nonwovens with elastic and middle materials, compressed by embossing units.
4. Nonwoven sectioning units adopts motor sectioning mode.
5. Tightness of elastic is adjusted by double roller linear velocity controlled by frequency conversion.
6. Roll material and tube material are compatible for elastic feeding.
7. Cotton core cutting and final product cutting adopt side blade scraping.
8. Color calibration of former icon straight cut adding unit.
9. Waist combination adopts heat seal.
10. Detailed shape, structure, sizes of products is confirmed according to the finalized products by both parties.
Pricing:0-1200000 usd
Payment Details:L/C,T/T,D/P
Min Order:1 SET
Ship Date:140 days
Standard Met:CE

Product Image

Full Servo pull up baby diapers machine 1
Img 1
Full Servo pull up baby diapers machine 2
Img 2
Full Servo pull up baby diapers machine 3
Img 3
Full Servo pull up baby diapers machine 4
Img 4
Full Servo pull up baby diapers machine 5
Img 5
Full Servo pull up baby diapers machine 6
Img 6
Full Servo pull up baby diapers machine 7
Img 7
Full Servo pull up baby diapers machine 8
Img 8
Full Servo pull up baby diapers machine 9
Img 9
Full Servo pull up baby diapers machine 10
Img 10
