| Model: | HA63M |
|---|---|
| Brand: | HUAYUE |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Sense Organ |
| Label: | encoder , wire draw encoder , wire pull encoder |
| Price: |
US $60
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:10 Jan, 2024 |
4 connection methods, cylindrical, circular, paperclip, and thread locking
Contact us for more product related information and the best prices
Choose the most suitable logistics for you.
Sensor type :Analog signal cable displacement sensor
Measuring Range :0-1500mm;0-2500mm
Linear Accuracy: 0.25% FS or 0.1% FS
Repeatability Accuracy: 0.01%
Output :4-20mA;0-10V;0-5V;0-10K;0-5K
Wire retraction force : 4N
Maximum reciprocating speed :600mm/s
Protection level outside the pull box: IP54
Life :More than 2 million reciprocating cycles
Operation temperature: -30℃~+90℃
Working voltage :5-30V;5V;12V;24V
Cable Length: Optional；Standard configuration 2m
Wire rope diameter: 0.6mm Imported coated steel wire rope
Housing Material: Aluminium alloy, oxidation surface treating,wear and corrosion prevention
