| Model: | Wanlisp4-300K14 |
|---|---|
| Brand: | wanlisonic |
| Origin: | Made In China |
| Category: | Agriculture & Foods / Processed Food / Other Processed Food |
| Label: | ultrasonic toast cut , bread cutter machine , ultrasonic machine |
| Price: |
US $16000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:09 Jun, 2022 |
Zhangzhou Wanli Machinery Co., Ltd.
Excellent Quality, Excellent Price & Excellent Service
Products Introduction
v Wanli ultrasonic cutting achieves no friction, no pressure cutting mode.
v It can cut sticky food such as cream jam smoothly and beautiful without sticking knife
v Automatic product positioning, Omni-directional cutting according to customer’s needs
v The cutting product can be automatically positioned and slitting according to the pre-entered parameters
Wanlisp4-300K1450L2000
It uses 4-axis servo driver system, can be applied to steel slat type of cake production line, with the advantage of high output, continuous cutting, convenient operation, automatic tracking, low failure rate, and highly automated, which make it can achieves 180 cuts/minute, besides of frequency ultrasonic scan and fault indicator lamp, this type has flip detection to avoid accidents.
Standard Parameter
|
Model |
Wanlisp4-300K1450L2000 |
|
Dimensions |
L2000*W900*H1400mm |
|
Weight |
Net Wt. 210KGS, Gross Wt.310KGS |
|
Voltage |
220V |
|
Rated power |
5000W |
|
Frequency |
50Hz-60Hz |
|
Ultrasonic Frequency |
20000Hz |
|
Amplitude |
20%-40% -40%
|
|
Cutting speed |
60 cuts/minute( adjustable) |
|
Number of blades |
3 (optional) |
|
Blade materials |
Titanium Alloy |
|
Blade size |
300mm/pc (optional) |
|
Cut type |
slices |
|
Maximum cutting size |
Width900mm, food cutting height up to 80mm, blade up height:100mm if food height is more than80mm,need to customize |
|
Material of machine frame |
Stainless Steel |
|
Automatic belt convey |
Yes |
|
Convey speed |
0-3000mm |
|
Safety protection system |
Security door, frequency ultrasonic scan and fault indicator lamp |
|
Control System |
Four-axis Control System |
|
Cutting knife control system |
Servo motor |
| Payment Terms: | 30% by TT as deposit,70% by TT after |
|---|---|
