| Model: | RL-H50 |
|---|---|
| Brand: | Reliablerfid |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | handheld PDA , barcode scanner , nfc handheld PDA |
| Price: |
US $275
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:16 Feb, 2020 |
RL-H50 is an Android r ed Handheld Terminal PDA. high-performance, high-reliability industrial-grade handheld barcode data terminal based on the Android 8.1 operating system. It has strong and stable performance, light and durable appearance, and supports 1D/2D barcode scanning,GPS. Positioning, photo taking, Wi-Fi, Bluetooth, 2G/3G/4G and other functions.
|
Model Number |
RL-RH50 |
|
|
PerformanceQuad-core
|
||
|
CPU |
Cortex-A53 64bit Quad-core 2.0GHz |
|
|
RAM+ROM |
2GB+16GB (Supports up to 3GB+32GB) |
|
|
Expansion |
Supports up to 128 GB Micro SD card |
|
|
Operating System |
Android 8.1 |
|
|
PerformanceOCTA core
|
|
|
|
CPU |
Cortex-A53 64bit Quad-core 2.0GHz |
|
|
RAM+ROM |
2GB+16GB (Supports up to 3GB+32GB/4GB+64GB) |
|
|
Expansion |
Supports up to 128 GB Micro SD card |
|
|
Operating System |
Android 9.0 |
|
|
Data Communication |
||
|
WLAN |
Dual-band 2.4GHz /5GHz, Supporting IEEE 802 a/b/g/n/ac protocol |
|
|
WWAN |
2G：GSM（850/900/1800/1900MHz） |
|
|
3G：WCDMA（850/900/1900/2100MHz） |
||
|
4G：FDD:B1/B3/B4/B7/B8/B12/B20,TDD:B38/B39/B40/B41 |
||
|
Bluetooth |
Support Bluetooth 2.0+EDR/3.0+HS/4.1+HS, transmission distance is 5-10m |
|
|
Physical Characteristics |
||
|
Dimensions 147.3mm×71.1mm×13.5mm |
||
|
Weight <500g ((Depends on device function configuration）) |
||
|
Display 5.5 inch IPS color display with resolution720*1440 |
||
|
TP Corning Gorilla glass, Supports multi-touch, Supported gloves and wet hands |
||
|
Power Rechargeable polymer battery (3.8V 4200mAh) removable |
||
|
Standby: over 350 hours
|
||
|
Continuous use: over 12 hours (depending on user environment) |
||
|
Charging time: 3-4 hours (with standard adaptor and USB cable)
|
||
|
Fast charging:1.5H（Optional） |
||
|
Expansion Slot PSAM x 2, Micro SIM card x 1 , TF card × 1 |
||
|
Interfaces Type-C USB x 1, OTG USB 2.0 Type-C, OTG
USB 2.0 Type-C, OTG
|
||
|
Audio Speaker (mono), Microphone, Earpiece
|
||
|
Keypad Silicone button: Power button, Volume +/- button, Scan button × 2 |
||
|
Sensor Gravity sensor, Light sensor, Proximity sensor, Vibration motor |
||
|
User Environment |
|
|
|
Operating Temp. |
-4°F to 122°F / -20°C to 50°C |
|
|
Storage Temp. |
-40°F to 158°F / -40°C to 70°C |
|
|
Humidity |
5%RH - 95%RH non condensing |
|
|
Drop Specification |
6 sides Supports 1.5 meters drops and 30 times to the concrete in the operating temperature
|
|
|
|
||
|
Rolling test |
500×0.5m rolling for 6 sides |
|
|
Protection Level |
IP-66 |
|
|
Data Collection |
||
|
Rear Camera
|
13MP HD camera, Support auto focus, Flash, Anti-shake, Macro shooting
|
|
|
Front Camera |
2MP color camera |
|
|
Barcode Scanning (Optional) |
||
|
2D Linear scanner |
Honeywell N3601/6603
|
|
|
2D Symbologies |
PDF417,Micro PDF417,GS1 Composite, Aztec Code, Data Matrix, QR Code, Micro QR Code, Maxicode, Hanxin Code,etc. Maxicode,Hanxin Code,etc. |
|
|
|
|
|
|
NFC (Optional) |
|
|
|
Frequency |
13.56MHz |
|
|
Protocol |
Support ISO14443A/B, ISO15693 |
|
|
Range |
2-5cm |
|
|
Language/input method |
|
|
|
Input |
English, Pinyin, Five strokes, Handwriting input, Support soft keypad |
|
|
Language |
Language packs in Simplified Chinese, Traditional Chinese, English, Korean, Japanese, Malaysian,etc. |
|
|
Accessories |
|
|
|
Standard Adapter, Data cable, Protective film, Instruction manual |
|
|
|
Optional Cradle, etc. |
|
|
