| Model: | Axis-500 |
|---|---|
| Brand: | Mingtai |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Machine Tool |
| Label: | Deep Hole Drilling , Deep Hole Drill , Deep Hole Drilling |
| Price: |
-
|
| Min. Order: | - |
| Live Chat: |  | Last Online:21 Aug, 2017 |
CNC Deep Hole Drilling Machine Technical Specifications
|
Machine Type |
DHD-300F |
DHD-500F |
DHD-600F |
DHD-800F |
DHD-1000F |
|
Number of Spindles |
1/2/4 |
1/2/4 |
1/2/4 |
1/2/4 |
1/2 |
|
Gundrilling Dia(mm) |
Ф2.5~Ф20 |
Ф2.5~Ф36 |
Ф2.5~Ф32 |
Ф2.5~Ф32 |
Ф16~Ф50 |
|
Max Drilling Depth (mm) |
300 |
500 |
600 |
800 |
1200/3000 |
|
Each Spindle Motor(kw) |
2.2 |
3 |
4 |
5.5 |
15 |
|
Spindle Speed(rpm) |
8000 |
8000 |
8000 |
4000 |
2500 |
|
Max Pressure of coolant (Mpa) |
16 |
16 |
10 |
8 |
6 |
|
CNC System |
Siemens/Fanuc |
||||
