| Model: | 688 |
|---|---|
| Brand: | Fada |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Hydraulic Pressure Machine & Parts |
| Label: | Floor Decking Machin , decking Machine |
| Price: |
US $30000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:26 Jul, 2020 |
1. Dimension:aboutc13M(L)*2.6M(W)*1.3M(H)
2. Total weight:about 14-15 Ton
3. Main motor power:380V 50HZ 11KW 2 SETS.Origin:Hengshui
4. Reducer :8# planetary cycloidal needle reducer.speed ratio:1:87
5. Mid-plate thickness:18mm.Origin:Shougang
6. Chainwheel、chains :1.5 inch single row.chainswheel:45# steel gear shaping、quenching
7. Principle roller:material 45#,diameter 95mm,production process
8. Mould of roller:45# steel forging,,through common lathe rough finish、CNC lathe,heat treatment,polishing,plating hard chrome formed.
9. Axis :24 rows
10.Frame:400mm “I” National standard
11. Thickness of sheet:0.8mm-1.5mm
12.Working speed:about 6-10m/min
13. Computer control the length and pieces.tolerance of length: ±3MM
14. Hydraulic pump station:main motor power 5.5kw.Origin:Shanghai
15. Cutting method:automatic hydraulic cutting.material of cutter:Gr12,kibble,heat treatment,accurate grinding,linearcutting.
16.Electric equipment:Mitsubishi PLC,Rip 600 encoder.Chint,DELIXI and other control parts
17．Feeding width:1000mm
| Payment Terms: | TT |
|---|---|
