| Model: | MX 403 |
|---|---|
| Brand: | M-Star |
| Origin: | Made In China |
| Category: | Chemicals / Chemical Lab Supplies |
| Label: | quartz cuvette , quartz cell , cuvette |
| Price: |
US $15
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:15 May, 2020 |
Product Description
Sizes and technical requirements determined by the customer, we guarantee the quality of the product!
Product Photos
Product Categories
|
Product number |
Product name |
Overall Dimension (mm) |
Optical path(mm) |
|
101 |
721 glass cell |
(9,14,24,34,44,54,104)*15*43 |
5,10,20,30,40,50,100 |
|
102 |
751 glass cell |
(3.5,4.5,5.5,7.4,12.4,22.4, 32.4,42.4,52.4,102.4)*12.4*45 |
1,2,3,5,10,20,30,40,50,100 |
|
103 |
Glass fluorescence four optical cuvette |
12.4*12.4*45 |
10 |
|
104 |
581 glass cell |
(9,14)*17.5*65 |
5,10 |
|
105 |
Setting tank Blood utensil Colorimeter cell Residual chlorine colorimeter |
18.5*23*100 9*9*50 29*17.5*75 29*16*70 |
13.5 5 25 25 |
|
106 |
Liquid sample cell |
(10.4, 14.0, 16.7, 29.4, 54.8, 104.0, 137.4)*20*40 |
6.4,10,12.7,25.4,50.8,100, 133.4 |
|
107 |
Glass cell with lid |
12.4*12.4*45 |
10 |
|
108 |
Quartz cell |
(3.5,4.5,5.5,7.4,12.4,22.4, 32.4,42.4,52.4,102.4)*12.4*45 |
1,2,3,5,10,20,30,40,50,100 |
|
109 |
Quartz bevel joint micro cell Glass bevel joint micro cell |
12.4*12.4*45 12.4*12.4*45 |
10 10 |
|
110 |
Quartz blackbody bevel joint micro cell
Glass blackbody bevel joint micro cell |
12.4*12.4*45
12.4*12.4*45
|
10
10 |
|
111 |
120 Quartz cell |
12.4*12.4*45 |
10 |
|
112 |
Quartz fluorescence four optical cuvette |
12.4*12.4*45 |
10 |
|
113 |
Quartz fluorescence four optical micro cuvette
Glass fluorescence four optical micro cuvette |
12.4*12.4*45
12.4*12.4*45 |
10
10 |
|
114 |
Quartz cell with lid |
12.4*12.4*45 |
10 |
|
115 |
Quartz micro cell with lid Glass micro cell with lid |
12.4*12.4*45 12.4*12.4*45 |
10 10 |
|
116 |
Quartz blackbody micro cell with lid Glass blackbody micro cell with lid |
12.4*12.4*45
12.4*12.4*45 |
10
10 |
|
117 |
Quartz fluorescence four optical micro cell with lid
Glass fluorescence four optical micro cell with lid |
12.4*12.4*45
12.4*12.4*45 |
10
10 |
|
118 |
Quartz fluorescence four optical cell with lid
Glass fluorescence four optical cell with lid |
12.4*12.4*45
12.4*12.4*45 |
10
10 |
|
119 |
721 Glass blackbody flowing cell |
(14,24,34)*15*43 |
10,20,30 |
|
120 |
Quartz blackbody flowing cell Glass blackbody flowing cell |
(12.4,22.4,32.4)*12.4*45 (12.4,22.4,32.4)*12.4*45 |
10,20,30 10,20,30 |
|
121 |
1/2 black and white flowing cell |
12.4*12.4*45 |
10 |
|
122 |
black and white flowing cell |
12.4*12.4*45 |
10 |
|
123 |
Granularity cuvette |
12*44*64 |
8 |
|
124 |
Biochemistry flowing cell |
12.4*12.4*35/15 |
10 |
|
|
|
|
|
Features
1. Mechanical strength, adapting abrupt change of temperature, bond departmentvery is very strong , which is resistant to several atmospheres pressure.
2. sophisticated optical processing technology, the optical properties of translucent surface is very good
3. Use high-quality quartz glass and optical glass, to ensure that no bubbles, no stripes.
4. High corrosion resistance, it can bear 6mol/L sodium hydroxide, 6mol/L hydrochloric acid, anhydrous ethyl alcohol, carbon tetrachloride, and benzene to erosion respectively for 24-hour non-degumming spillage, and no leakage
Factory Show
Professional manufacture of cuvettes, we supply all kinds of cuvettes. Our factory has decades of production experience, we supply various specifications cuvettes, optical components, glass instrument for major analytical instrument factory.
Cuvette (also known as the absorption cell, the sample cell) used to hold the reference solution, a sample liquid. Supporting spectroscopic instrument, substance quantitative and qualitative analysis, widely used in the chemical industry, metallurgy, medical, pharmaceutical, food, environmental protection, power plants, water plants, oil and other industries, departments, colleges and universities, research institutes test laboratory use. Wavelength range can be divided into three series, namely visible light series (called glass cuvette), UV-Vis series (known as quartz cuvette), infrared light series (known as infrared cuvette)
Our Services
1.Factory direct sale
2. Industry and trade integration business
3.More than 15 years experience
4.Customize size are welcome,OEM,ODM acceptable
5. Fast,accurate quotes
6.The best price with good quality
7. We offer a good after-sales service
8.Payment: T/T,Western Union,L/C
| Payment Terms: | TT/ Western Union |
|---|---|
