Capacitive Oil Transmitter
Overview:
Capacitive Oil Transmitter is based on the measured hydrostatic liquid level height with the principle of proportionality, adapt the isolation-type proliferation of advanced silicon sensor or ceramic capacitance sensor, It detects circuit through accurate temperature compensation and linearity correction, thus convert the static pressure into a standard signals (normally is 4 ~ 20 mA). At the same time, you can choose 4 ~ 20 mA, 1 ~ 5V, 0 ~ 10 mA as required.
It can be widely used for petroleum, chemical industry, metallurgy, electric power, pharmaceuticals, water supply and drainage etc. Compact structure and flexible way for users to easily installed to provide a convenient to use.
Performance index:
● Detection range: 100~2000mm
● Precision: ±1%F.S.
● Temperature drift：≤0.02%FS/℃ ( 0-70℃)
● working Temperature：-20~ +85℃
● Output signal: 4～20mA ,0~10V,0-5V,RS485,RS232
● Power voltage: 5～40V DC
● Wetted-body material: SUS304 、AL
