non-phosphorous Cooling water system
corrosion and scale inhibitor AE3150
Characteristic
● Controls deposition and scale with non-phosphonate technology
● Maximizes corrosion protection without heavy metals
● Eliminates or minimizes acid feed
● Stable in presence of halogens
Description and Use
AE3150 IS designed blends containing alkyl epoxy carboxylate, a non-phosphorous calcium carbonate inhibitor, as the primary ingredient used for deposit control.
Technical Specification
|
Serials No.
|
Item
|
Index
|
|
1
|
Appearance
|
Clear light yellow, liquid
|
|
2
|
Density,g/cm3
|
1.10--1.30
|
|
3
|
PH
|
>12
|
|
5
|
Solubility
|
Completely soluble in water
|
|
6
|
Smell
|
nonirritant
|
Typical Applications
AE3150 is designed for cooling water systems operating at alkaline Ph(7-8.3). This means that acid feed and the costs and concerns associated with it may be reducedor eliminated.It is versatile and have been successfully used in a broad range of systems operating under varying conditions.
AE Series products inhibit the corrosion of mild steel and copper and its alloys. They effectively control common scales, such as calcium carbonate and calcium phosphate, and fouling, due to iron and other suspended solids. The particular combination of active ingredients required to give the desired results depend on the system metallurgy, temperature, water chemistry and other system characteristics.
Treatment And Feeding Requirements
Dosage:The proper treatment level of AE Series products depends on the individual formulation and needs of your system. The product should be fed in accordance with control parameters. For consistent protection, continuous feed if recommended.
Feedpoint:AE Series products should be fed to a point in the cooling system where they can rapidly mix with the bulk cooling water.
Feed Equipment:
Tanks, pumps, piping and valves should be made of mild steel, stainless steel, polyethylene or most common plastics.
Dilution: For best results, AE Series products should be fed neat. Dilutions, if necessary, are best made with low hardness water.
General Properties
Physical properties of AE Series products are shown on the Material Safety Data Sheet (MSDS), a copy of which is available on request.
Packaging Information
AE Series products are liquid blends, available in a variety of containers and delivery methods. Contact our representative for details.
Storage
Protect from freezing. If these products are frozen during shipment or storage, slight mixing may be required to ensure homogeneity.
Safety Precautions
An MSDS containing detailed information about each specific product in this Series is available upon request
