Table Saw Machine with Dado, HW110LGE-50

Model:HW110LGE-5
Brand:SHOOT
Origin:Made In China
Category:Industrial Supplies / Tools / Woodworking
Label:woodworking machine , table saw , sliding table saw
Price: -
Min. Order:5 pc
Inquire Now Add to Basket

Member Information

Detail

Yantai Shoot Woodworking Machine Co.,Ltd

Biz MemberShan Dong - China
Live Chat:
Last Online:09 Apr, 2024

View all products. (841)

Product Description

Table Saw Machine with Dado function
Models            HW110LGE-50
 Main table      512  x 685mm
 Extension wings      254  x 685mm
 Blade diameter      254mm
 Electric motor(TEFC)      2.2Kw/220V/50HZ/1PH
 Spindle speed      4150RPM
 Arbor tilt      Left
 Max.cut depth@0°      80mm
 Max.cut depth@45°      57mm
 Max.rip cut(blade right)      762mm(1270mm)
 Max.rip cut(blade left)      305mm
 Dado diameter      203mm
 Dado Max. width      20.6mm
 Arbor size      30mm
 T-slots      19 x 9.5mm
 Dust colletion port      100mm
 Belts      3 x V-belts
 Switch       Magnetic
 Worktable height      863mm
 Machine weight      240kgs (255kgs)
 Foot print      515 x 515mm
