Large scale multi-axial CNC cutting machine group for wide and heavy plate in thermal state is applicable for the continual casting and rolling cutting of wide and heavy plate in large scale metallurgy industry, and finds its vast potential for future development in many industries such as large scale ship-building industry, defence industry enterprise, gas transmission from the west to the east, large scale power station, mine industry and so on. Which can not only substitute  imported product,save  foreigh currency, but also can promote the technical following up of domestic enterprises, improve technical level of home made heavy equipments


Technical innovation
1)Continual cutting at high-temperature environment(Max. temperature of steel plate 350℃,Max. ambient temperature 60℃. the latest world advanced technology);2) extra width and thickness (Max.width of steel plate 5m,thickness as much as 300mm);3)profile of steel plate generated by automatic scanning(the latest world advanced technology);4) double workstation cutting and multi-axial control(as much as 26 axes,the latest world technology level);5)  concurrent cutting of longitudinal and wasted slitteredge(the world latest technology);6)automatic nesting and optimized cutting path of cutting sub-plate and sample workpiece; 7) temperature compensation during the course of cutting(the world latest technology);8) automatic berth of cutting torch; () punching character and mark on the sub-plate and sample workpiece; 10) monitoring and alarming on the spot; 11) cutting LP steel plate with variable section; 12) network communication(three grade management of spot,workshop,factory; 13) automatic control for cutting parameter.
