| Model: | PIM |
|---|---|
| Brand: | FAE |
| Origin: | Made In China |
| Category: | Industrial Supplies / Electrical & Electronic Product Equipment |
| Label: | pin insertion machin , auto-inserting pin , pin insertion |
| Price: |
¥60000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:27 Dec, 2023 |
ØApplicationS
ØIt is applied to all type of Pin insertion in HDDfield,such as Bias pin, FPC pin,Ground pin,Latch pin,…etc
ØIt is also applied to the Pin insertion in other field.
ØFeatures
ØPin feed by Vibrating tray
ØVacuum mechanism fetch the pin and placement, Digital Vcuum pressure switch with LCD readout to full proof thepin missing
ØProfessional technology to ensure the capability of Pin insertion.
ØIndustry safety light curtain
ØProgrammable homework shows on front-panel
ØSpecifications
Item | Spec. | Item | Spec. |
Efficiency of feeder | 300 pcs/min | Max. loading of Z axis | |
X axis travel ranges | UPH | 500pcs/hr | |
Repetitive precision of X axis | Power supply / Air pressure | 220V/50Hz 0.7Mpa(Max) | |
Max. move speed of X axis | Size / Weight | 615*445* |
ØParameter setting
It can easily check the running status of Motors, Cylinders and other motion units, and promptly set or reset the parameters for these units based on your findings.
