RF Power Triode BW1608J2F
BW1608J2F is a water cooled, metal /
ceramic power triode. It uses a thoriated
tungsten filament and a coaxial structure,
intended for use in industrial radio frequency
heating as oscillator. Max. frequency:
30MHZ, max plate dissipation: 50KW.
Output power (class C oscillator, less
driver): 118 kw
ABRIDGED DATA
Two RF power triodes of coaxial
ceramic/metal construction, intended
primarily for industrial service. They differ
only in the method of anode cooling and
anode dissipation.
Anode cooling. . . . . . . . water; integral
jacket
Anode dissipation . . . . . . . . . .50 kWmax
Anode voltage . . . . . . . . . 13 kVmax
Frequency for full ratings . . . . .30 MHzmax
Output power (class C oscillator,
less drive) . . . . . . . . . . .118 kW
GENERAL Electrical
Filament . . . . . . . . . . . thoriated tungsten
Filament voltage . . . . . ……12 V
Filament current. . . . . . . . .178 A
Surge filament current (peak) . 890 Amax
Filament cold resistance . . . . 8.0 mO
Peak usable cathode current . . 70 A
Amplification factor
(Va = 10 kV, Ia=5.0A) . . . 40
Mutual conductance
(Va = 10 kV, Ia=5.0A) . . . 80 mA/V

Inter-electrode capacitances:
grid to anode . . . . . . . . .47 pF
grid to filament . . . . . . . .126 pF
anode to filament . . . . . . .2.0 pF
Mechanical
Overall dimensions . . . . . . seeoutline drawings
Net weight . . . . . . . . . . . 12Kg approx
Mounting position . . . vertical, either way up
