 Wireless Home alarm system

Product Details:
Place of Origin: Guangdong, China
Brand Name: AOLIN
Model Number: AL-4108

Payment & Shipping Terms:
Minimum Order Quantity: 10 Set/Sets
Packaging Details: gift box
Delivery Time: 20days
Payment Terms: T/T,Western Union
Supply Ability: 30000 Set/Sets per Month

1. Compatible with 8 wired and 8 wireless zones

2. Zones controllable by ID card mobile and remote controller.

3. Keypad operation, LCD display

4. Easily set alarming telephone, password, time & date, armed zones.

5. Panic alarm

6. CMS&GSM optional, support Ademco Contact ID.

7. Select armed zones separately.

8. Integration

9. 36 event log to record the alarming scene

10. Record and play back.

11. Remote control.

12. Urgent calling.

13. Flexible configuring.

14. Display Arm delay, alarm delay and alarming time.

15. Could work with 12V SLA backup battery

16. Power (12v) output port.

17. External accessing to the light

18. Alarm automatically for telephone lines being cut or in error.

19. Sound for the door is opened

20. Special functions for remote control.

Technology Parameter:

(1) Power supply: AC: 220V±10%

(2) Standby current: ≤56mA ( excluding wired accessories)

(3) Keypad current:≤36mA

(4) Alarming current: <196mA( excluding external siren)

(5) Receiving frequency: 433.92±0.5MHz

(6) Preset telephone number: 3 groups, 1 CMS NO. , 1 USER ID

(7) Standby battery: 12V, 4.5AH or 7 AH SLA battery

(8) Standby time:≥20 hours.

(9) Wireless receiving distance: ≥150m

(10) Trigger way(wired accessories): be cut

(11) Trigger holding: 0.5 second.

(12) Defense areas: wireless zones 8, wired defense zones8.
