> Rated Power: 20W

> Working Voltage: 85-264VAC, 277VAC, 50/60Hz;

> Panel Outline Dimension: L300*W300*T12mm

> LED Quantity: 310pcs SMD3014 LED

> Efficiency: 90% Min.

> Luminous Flux: 1800 Lm+/-10%

> Colour Rendering Index: 80 Ra.

> Colour Temperature: 2700K - 7000K

> Product Life: >50K Hrs.

> Power Factory: 0.95@240VAC, 0.99@90VAC

> Working Temperature: -40 ~ +55 Degrees

> Working Humidity: 95% RH

> Certification: CE, RoHs

> Case Material: Aluminum

Product Package：

1. Inner Box: L350*W370*H80mm, 1pcs per Box.

2. Carton Dimension: L760*W680*H360mm, 20pcs per carton.

3. G.W.: 30KG

Product Characters：

ü  Ultra slim, only 12mm thickness, low weight.

ü  Super bright LED, adopt latest LED technology, high quality SMD3528 and SMD3014, low light decay, longer lifespan >50 000 hours.

ü  High quality constant current LED driver, fully meet UL, PSE, CE, TUV and others global safety & EMC requirements, the external LED driver put at outside of the panel light.

ü  Special design on the light guide, adopt high transmit ratio material PMMA, improved light efficiency, and even illumination, no dark area.

ü  Pure aluminum frame and back cover for excellent thermal dissipation.

ü  High-conductivity aluminum PCB, rapid thermal dissipation, quality guaranteed.

ü  Optimal circuit design and LED arrangement on the AL. PCB.

ü  No UV & IR, No radiation, No electromagnetic interference, No hazard material as Hg & Leads etc.

Application:

The LED panel light is mainly for indoor illumination, such as for:

• Office
• School
• Hospital
• Restaurant
• Supermarket
• Metro
